Airtac TTQ Stopper Cylinder TTQ25X10B
1. Complies with JIS standards;
2. Reinforced piston rod design significantly enhances impact resistance;
3. Fixed mounting height with multiple rod end configurations - Optional hydraulic shock absorber delivers superior cushioning performance;
4. Lever roller mechanism integrates self-locking device that prevents arm rebound and ensures secure obstruction of target objects;
5. Comprehensive series/specification options for flexible integration into diverse applications.
Category: Stop Cylinders , Brand: AirTAC , Series: TTQ
AirTAC TTQ Series Stopper Cylinder TTQ25X10B Technical Details
- Model Code: TTQ25X10B
- Type: Double-acting compact stopper cylinder
- Bore size: Ø25mm (±0.1mm manufacturing tolerance)
- Stroke: 10mm (adjustable via mechanical stopper)
- Operating pressure: 0.1-1.0 MPa (14.5-145 PSI)
- Piston speed: 50-800 mm/s (lubricated condition)
- Cushioning: Rubber buffer + adjustable air cushion
- Port size: Rc1/8 (NPT1/8 optional)
- Ambient temperature: -20℃ to 80℃ (NBR seals)
- Repeat positioning accuracy: ±0.2mm
- Mounting: Standard M5 threaded holes (4x)
- Piston rod material: Chrome-plated carbon steel (S45C)
- Body material: Anodized aluminum alloy
- Weight: 0.54kg (1.19lbs) ±3%
- Dimensions: 100mm(L) × 45mm(W) × 45mm(H) (excl. mounting protrusions)
- Protection class: IP54 (standard), IP67 available on request
- Air consumption: 9.8cm³/stroke at 0.5MPa
High-precision stopper cylinder with integrated shock absorption system, featuring dual-position magnetic sensor slots for automated feedback. The hardened stainless steel guide rod ensures wear resistance in high-cycle applications (up to 15 million cycles at rated load). Optimized air passage design reduces response time to 30ms under 0.5MPa pressure.
- PCB board positioning in SMT assembly lines
- Workpiece clamping in CNC rotary tables
- Carton alignment systems in packaging machinery
- Precision stopper for automotive part conveyors
- Glass panel temporary fixation in display manufacturing
Installation guidelines:
Maintain 0.5-1mm clearance between stopper tip and target surface during setup.
Lubricate with ISO VG32 hydraulic oil monthly in dusty environments. Avoid side
impact forces exceeding 50N to prevent guide rod deformation.
| Property | Property Value |
|---|---|
| sku | TTQ25X10B |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Bore Diameter | <25 mm> |
| Self-locking Function | Non Self-locking |
| Stroke | <10mm> |
| Blocking Method | Flat Cylinder |
