Airtac TTQ Stopper Cylinder TTQ25X10C
1. Complies with JIS standards;
2. Reinforced piston rod design significantly enhances impact resistance;
3. Fixed mounting height with multiple rod end configurations - Optional hydraulic shock absorber delivers superior cushioning performance;
4. Lever roller mechanism integrates self-locking device that prevents arm rebound and ensures secure obstruction of target objects;
5. Comprehensive series/specification options for flexible integration into diverse applications.
Category: Stop Cylinders , Brand: AirTAC , Series: TTQ
AirTAC TTQ Series Stopper Cylinder TTQ25X10C Specifications
- Model: TTQ25X10C
- Type: Double-acting stopper cylinder with mechanical lock
- Bore size: Ø25mm
- Stroke: 10mm
- Operating pressure: 0.1-0.8 MPa
- Cushioning type: Adjustable pneumatic cushion (both ends)
- Mounting style: Side-mounted with M6×1.0 threaded holes
- Operating temperature: -20℃ to 80℃
- Port size: M5×0.8 (standard) / NPT1/8 optional
- Weight: 0.85kg (excluding accessories)
- Dimensions: 150mm(L) × 80mm(W) × 80mm(H)
- Material: Aluminum alloy cylinder tube / Chrome-plated piston rod
- Seal material: NBR + PU combination
- Repeat positioning accuracy: ±0.5mm
- Maximum lateral load: 250N
High-precision stopper cylinder designed for precise workpiece positioning in automated systems. Features dual-guide rod stabilization and wear-resistant seals for 5,000km+ service life. The T-slot mounting surface allows flexible accessory integration. Requires ISO 8573-1:2010 Class 3 compressed air.
- Pallet stop mechanisms in conveyor systems
- Precision fixturing for CNC machine loading
- Position locking in robotic assembly stations
- Carton positioning in packaging machinery
- Elevator-type workpiece stoppers
Operational guidance:
Lubricate with ISO VG32 hydraulic oil mist (1 drop/cycle recommended).
Maintain 0.3-0.6 MPa pressure for optimal cushioning performance.
Avoid side impact forces exceeding 150N during operation.
| Property | Property Value |
|---|---|
| sku | TTQ25X10C |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Bore Diameter | <25 mm> |
| Self-locking Function | Non Self-locking |
| Stroke | <10mm> |
| Blocking Method | Round Type |
