Airtac TTQ Stopper Cylinder TTQ25X10SB
1. Complies with JIS standards;
2. Reinforced piston rod design significantly enhances impact resistance;
3. Fixed mounting height with multiple rod end configurations - Optional hydraulic shock absorber delivers superior cushioning performance;
4. Lever roller mechanism integrates self-locking device that prevents arm rebound and ensures secure obstruction of target objects;
5. Comprehensive series/specification options for flexible integration into diverse applications.
Category: Stop Cylinders , Brand: AirTAC , Series: TTQ
AirTAC TTQ25X10SB Stopper Cylinder Specifications
- Model: TTQ25X10SB
- Type: Double-acting stopping cylinder with built-in guide
- Bore size: Ø25mm
- Stroke: 10mm ±0.5mm
- Operating pressure: 0.05–0.9 MPa
- Operating temperature: 0℃ to 60℃
- Cushioning type: Fixed rubber buffer + adjustable cushion
- Port size: M5x0.8 (G1/8 optional)
- Piston speed: 50–500mm/s
- Repeat positioning accuracy: ±0.1mm
- Rod material: SCM435 chrome-plated steel
- Body material: Aluminum alloy (anodized)
- Seal material: NBR
- Weight: 0.68kg ±2%
- Dimensions: 78mm(L) × 54mm(W) × 54mm(H)
- Mounting type: 2xM5 threaded holes on base
- Protection rating: IP54
Precision-guided stopping cylinder with dual-position detection slots, designed for high-accuracy workpiece positioning in automated assembly lines. Features wear-resistant guide rails and dual shock absorption system. Requires 5μm filtered air with ISO VG32 lubricant (optional oil-free operation).
- PCB conveyor positioning systems
- Robotic arm pick-and-place station stoppers
- Automotive part assembly jigs
- Pharmaceutical blister packaging machines
- 3C product testing equipment positioning
Installation note:
Align guide rail direction with motion axis. Lubricate sliding surfaces with
ISO VG32 oil monthly in continuous operation. Max lateral load: 15N.
| Property | Property Value |
|---|---|
| sku | TTQ25X10SB |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <25 mm> |
| Self-locking Function | Non Self-locking |
| Stroke | <10mm> |
| Blocking Method | Flat Cylinder |
