Airtac TTQ Stopper Cylinder TTQ25X10SC
1. Complies with JIS standards;
2. Reinforced piston rod design significantly enhances impact resistance;
3. Fixed mounting height with multiple rod end configurations - Optional hydraulic shock absorber delivers superior cushioning performance;
4. Lever roller mechanism integrates self-locking device that prevents arm rebound and ensures secure obstruction of target objects;
5. Comprehensive series/specification options for flexible integration into diverse applications.
Category: Stop Cylinders , Brand: AirTAC , Series: TTQ
AirTAC TTQ25X10SC Blocking Cylinder Specifications
- Model: TTQ25X10SC
- Type: Double-acting compact blocking cylinder with spring return
- Bore size: 25mm
- Stroke: 10mm ±0.5mm
- Operating pressure: 0.1–0.9 MPa
- Cushioning: Adjustable rubber buffer (both ends)
- Port size: 1/8 PT (G1/8 optional)
- Piston speed: 50–800 mm/s
- Ambient temperature: -20℃ to 80℃
- Seal material: NBR + PU hybrid seals
- Mounting options: Front flange (MF1), rear flange (MF2), foot mounting (MB)
- Repeat accuracy: ±0.1mm
- Weight: 0.45kg ±5%
- Dimensions: 80mm(L) × 25mm(W) × 25mm(H) (excluding rod)
- Rod thread: M6×1.0
- Protection rating: IP54 (standard)
- Optional sensors: Built-in magnet compatible with D-A93 series magnetic switches
High-precision blocking cylinder engineered for precise workpiece positioning and emergency stop functions. Features anti-rotation design with hardened chrome piston rod (HRC 45-50) and self-lubricating guide bushings. Optimized for high cycle rates up to 3,000 cycles/hour with ≤0.15mm lateral play. Requires ISO 8573-1:2010 Class 3 lubricated air.
- Pallet stop mechanisms in conveyor systems
- Precision registration in semiconductor handling
- Tooling plate positioning for CNC fixtures
- Safety interlocks in automated assembly lines
- Part ejection control in high-speed presses
Installation guidelines:
Maintain 0.5-1mm clearance between blocking face and target surface.
For vertical mounting, use auxiliary rod support brackets (ASQ-25 accessory recommended).
Lubricate every 50,000 cycles using ISO VG32 turbine oil.
| Property | Property Value |
|---|---|
| sku | TTQ25X10SC |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <25 mm> |
| Self-locking Function | Non Self-locking |
| Stroke | <10mm> |
| Blocking Method | Round Type |
