Airtac TTQ Stopper Cylinder TTQ25X10SR
1. Complies with JIS standards;
2. Reinforced piston rod design significantly enhances impact resistance;
3. Fixed mounting height with multiple rod end configurations - Optional hydraulic shock absorber delivers superior cushioning performance;
4. Lever roller mechanism integrates self-locking device that prevents arm rebound and ensures secure obstruction of target objects;
5. Comprehensive series/specification options for flexible integration into diverse applications.
Category: Stop Cylinders , Brand: AirTAC , Series: TTQ
AirTAC TTQ Series Blocking Cylinder TTQ25X10SR Technical Specifications
- Model: TTQ25X10SR
- Type: Double-acting linear blocking cylinder with magnetic sensor
- Bore size: Ø25mm
- Stroke: 10mm (±1mm adjustable)
- Operating pressure: 0.1–0.8 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Temperature range: -20℃ to 80℃
- Seal material: NBR (nitrile rubber) standard, optional FKM/Viton
- Port size: Rc1/8 (G1/8 adaptor included)
- Mounting: Front flange (ISO 15552 standard)
- Weight: 0.68kg (without sensor), 0.72kg (with sensor)
- Dimensions: 133mm(L) × 25mm(Bore) × 60mm(H) (retracted position)
- Extended length: 143mm (fully extended)
- Sensor type: Reed switch (2-wire)
- Sensor voltage: DC5-24V (±10%)
- Protection class: IP67 (cylinder body), IP65 (sensor)
High-precision stopping cylinder with integrated position detection, featuring hardened steel guide rods and anodized aluminum body. The TTQ25X10SR combines 0.01mm repeat positioning accuracy with lateral load resistance up to 150N, making it ideal for precision automation systems. Requires 40μm filtered air with lubrication (ISO VG32 recommended).
- PCB board positioning in SMT assembly lines
- Workpiece clamping in CNC machining centers
- Precision stopper for robotic pick-and-place systems
- Bottle cap alignment in packaging machinery
- Automated inspection equipment gates
Installation note:
Mount on rigid surfaces using M5x0.8 mounting screws (ISO 4762) with 20N·m torque.
Maintain 0.5mm minimum clearance between piston rod and workpiece during impact.
For vertical installations, use in push-down configuration only.
| Property | Property Value |
|---|---|
| sku | TTQ25X10SR |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <25 mm> |
| Self-locking Function | Non Self-locking |
| Stroke | <10mm> |
| Blocking Method | Roller Type |
