Airtac TTQ Stopper Cylinder TTQ25X15B
1. Complies with JIS standards;
2. Reinforced piston rod design significantly enhances impact resistance;
3. Fixed mounting height with multiple rod end configurations - Optional hydraulic shock absorber delivers superior cushioning performance;
4. Lever roller mechanism integrates self-locking device that prevents arm rebound and ensures secure obstruction of target objects;
5. Comprehensive series/specification options for flexible integration into diverse applications.
Category: Stop Cylinders , Brand: AirTAC , Series: TTQ
AirTAC TTQ Series Stopper Cylinder TTQ25X15B Technical Details
- Model: TTQ25X15B
- Type: Compact double-acting stopping cylinder
- Bore size: Ø25mm
- Stroke: 15mm (±1mm tolerance)
- Operating pressure: 0.1–0.8 MPa
- Cushioning type: Elastic cushion both ends
- Mounting style: Female thread (M10×1.25 mounting holes)
- Port size: M5×0.8 (standard) with NPT1/8 adapter option
- Temperature range: -10℃ to 70℃ (NBR seals)
- Body material: Aluminum alloy with hard anodized surface
- Rod material: Stainless steel (SUS304)
- Protection rating: IP40 (standard), IP67 optional
- Weight: 0.85kg ±3% (including accessories)
- Dimensions: 125mm(L) × 25mm(Bore) × 32mm(Mounting height)
High-precision mechanical stopper designed for position locking in automated systems. Features zero-point repeatability ≤±0.2mm and impact energy absorption up to 2.5J. Integrated shock absorber reduces vibration during abrupt stops. Optional magnetic sensor slots (M5×0.5 threaded) for position feedback.
- Workpiece positioning in CNC loading/unloading systems
- Conveyor line product separation gates
- Robotic arm end effector alignment stops
- Precision fixture locking in semiconductor handling
- Packaging machine product counting stations
Installation guidelines:
Maintain 0.5mm minimum clearance between stopper face and target surface.
Lubricate rod with ISO VG32 hydraulic oil monthly. Avoid side-load forces exceeding 15N.
| Property | Property Value |
|---|---|
| sku | TTQ25X15B |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Bore Diameter | <25 mm> |
| Self-locking Function | Non Self-locking |
| Stroke | <15mm> |
| Blocking Method | Flat Cylinder |
