Airtac TTQ Stopper Cylinder TTQ25X15C
1. Complies with JIS standards;
2. Reinforced piston rod design significantly enhances impact resistance;
3. Fixed mounting height with multiple rod end configurations - Optional hydraulic shock absorber delivers superior cushioning performance;
4. Lever roller mechanism integrates self-locking device that prevents arm rebound and ensures secure obstruction of target objects;
5. Comprehensive series/specification options for flexible integration into diverse applications.
Category: Stop Cylinders , Brand: AirTAC , Series: TTQ
AirTAC TTQ Series Blocking Cylinder TTQ25X15C Specifications
- Model: TTQ25X15C
- Type: Compact double-acting blocking cylinder
- Bore size: 25mm
- Stroke: 15mm
- Operating pressure: 0.1–0.8 MPa
- Cushioning type: Adjustable pneumatic cushion
- Operating temperature: -20℃ to 80℃
- Mounting style: Standard base mount (optional flange/bracket kits)
- Port size: PT1/8 (M5×0.8 optional)
- Piston rod material: Hard chrome-plated steel
- Tube material: Aluminum alloy with oxidation-resistant coating
- Seal material: NBR (Nitrile rubber)
- Weight: 0.62kg ±2%
- Dimensions (L×W×H):
- Basic length: 62mm
- Full extended length: 77mm (62+15mm stroke)
- Body width: 40mm
- Mounting base height: 12mm
- Max thrust: 127N at 0.6MPa (extend), 112N (retract)
- Response time: ≤0.3s (at 0.5MPa)
- IP rating: IP54 (standard), IP67 optional
A precision-engineered blocking cylinder featuring integrated mechanical stops for position locking. The TTQ25X15C combines compact dimensions with 25kN/m anti-vibration capacity, making it ideal for repetitive precision tasks. Includes wear-compensation seals and dual guide rods for enhanced lateral load resistance. Requires 5μm filtered air (ISO 8573-1 class 3).
- Conveyor line workpiece positioning gates
- Robotic arm end-effector braking systems
- Semiconductor wafer handling lock mechanisms
- Automated assembly station part retention
- Packaging machine product flow control
Installation recommendation:
Maintain 0.5-1mm clearance between blocking surfaces during setup.
Lubricate with ISO VG32 pneumatic oil (2-3 drops/month continuous operation).
Avoid side-load exceeding 50N during locking phase.
| Property | Property Value |
|---|---|
| sku | TTQ25X15C |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Bore Diameter | <25 mm> |
| Self-locking Function | Non Self-locking |
| Stroke | <15mm> |
| Blocking Method | Round Type |
