Airtac TTQ Stopper Cylinder TTQ25X15SB
1. Complies with JIS standards;
2. Reinforced piston rod design significantly enhances impact resistance;
3. Fixed mounting height with multiple rod end configurations - Optional hydraulic shock absorber delivers superior cushioning performance;
4. Lever roller mechanism integrates self-locking device that prevents arm rebound and ensures secure obstruction of target objects;
5. Comprehensive series/specification options for flexible integration into diverse applications.
Category: Stop Cylinders , Brand: AirTAC , Series: TTQ
AirTAC TTQ25X15SB Stopper Cylinder Specifications
- Model: TTQ25X15SB
- Type: Double-acting stopper cylinder with magnetic switch
- Bore size: Ø25mm
- Stroke: 15mm
- Operating pressure: 0.05–0.9 MPa
- Cushioning: Adjustable rubber buffer
- Mounting: Standard base mount (FNPT 1/8 ports)
- Port thread: Rc1/8 (NPT optional)
- Temperature range: -10℃ to 80℃
- Body material: Aluminum alloy (hard anodized)
- Rod material: Stainless steel (SUS304)
- Seal material: NBR + PU combination
- Weight: 0.85kg ±2%
- Dimensions: 150mm(L) × 40mm(W) × 40mm(H) (extended length)
- Repeat accuracy: ±0.5mm
- Max thrust: 147N @0.5MPa
- Switch type: Reed sensor (2-wire PNP)
- Protection rating: IP67
Precision stopper cylinder with integrated position detection, featuring dual anti-rotation guide rods for enhanced lateral stability. The hardened piston rod and wear-resistant seals enable high-cycle operations (up to 5 million cycles). Includes 3-position mounting holes for flexible installation alignment.
- Pallet positioning in conveyor systems
- Workpiece clamping in CNC machining centers
- Carton alignment in packaging machinery
- Precision stopping in automated assembly lines
- Tooling fixture positioning in automotive welding jigs
Installation note:
Ensure proper alignment of guide rods parallel to workpiece movement axis.
Lubricate with ISO VG32 hydraulic oil before initial use.
Maintain 0.3mm minimum clearance between stopper plate and cylinder body during operation.
| Property | Property Value |
|---|---|
| sku | TTQ25X15SB |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <25 mm> |
| Self-locking Function | Non Self-locking |
| Stroke | <15mm> |
| Blocking Method | Flat Cylinder |
