Airtac TTQ Stopper Cylinder TTQ25X15SC
1. Complies with JIS standards;
2. Reinforced piston rod design significantly enhances impact resistance;
3. Fixed mounting height with multiple rod end configurations - Optional hydraulic shock absorber delivers superior cushioning performance;
4. Lever roller mechanism integrates self-locking device that prevents arm rebound and ensures secure obstruction of target objects;
5. Comprehensive series/specification options for flexible integration into diverse applications.
Category: Stop Cylinders , Brand: AirTAC , Series: TTQ
AirTAC TTQ Series Stopper Cylinder TTQ25X15SC Technical Details
- Model: TTQ25X15SC
- Type: Compact rodless stopper cylinder (double-acting)
- Bore size: Ø25mm
- Stroke: 15mm (adjustable)
- Operation method: Pneumatic spring return
- Working pressure: 0.1–0.9 MPa
- Buffer type: Rubber cushion + shock absorber
- Port size: M5x0.8 (dual ports)
- Seal material: NBR + polyurethane hybrid
- Temperature range: -10℃ to 80℃
- Repeat positioning accuracy: ±0.2mm
- Protection rating: IP40
- Weight: 1.2kg (with mounting bracket)
- Dimensions: 140mm(L) × 55mm(W) × 55mm(H)
- Mounting hole spacing: 30mm (vertical/horizontal)
Precision stopper cylinder featuring zero-point positioning capability and magnetic piston for sensor integration. The hardened stainless steel guide rod (HRC 45-50) ensures wear resistance in high-cycle applications. Includes anti-rotation mechanism for stable vertical/horizontal mounting.
- Workpiece positioning in conveyor systems
- Robotic arm end-effector braking
- Carton flap control in packaging machinery
- PCB board retention during SMT processes
- Pallet alignment in AS/RS warehouses
Installation note:
Requires 0.5mm lateral clearance during alignment. Use with
AIRTAC MLQ2-10D magnetic sensor for position feedback.
Lubricate sliding surfaces with ISO VG32 hydraulic oil monthly.
Avoid side load >50N. Maximum allowable impact energy: 0.3J.
Install mechanical stopper when used in vertical downward orientation.
| Property | Property Value |
|---|---|
| sku | TTQ25X15SC |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <25 mm> |
| Self-locking Function | Non Self-locking |
| Stroke | <15mm> |
| Blocking Method | Round Type |
