Airtac TWG Stop Cylinder TWG32X10R
2、Reinforced piston rod design significantly enhances cylinder's resistance to lateral bending moments;
3、Adjustable mounting height with multiple rod end configurations, optional oil-cushioned shock absorber ensures superior damping performance;
4、Lever-type roller mechanism integrated with self-locking device prevents arm rebound-induced pushback on blocked objects;
5、Multiple series and specifications available to meet diverse industrial automation requirements.
Category: Blocking Cylinder | Brand: AIRTAC | Series: TWG
AirTAC TWG Series Stopper Cylinder TWG32X10R Technical Specifications
- Model: TWG32X10R
- Type: Double-acting adjustable stopper cylinder
- Bore size: 32mm
- Stroke: 10mm (standard)
- Operating pressure: 0.1–0.8 MPa
- Medium: Dry air (Lubricated operation requires ISO VG32 oil)
- Cushioning: Adjustable rubber buffer + external shock absorber
- Mounting: Standard foot-mounted (MF1) with multiple accessory options
- Rod end: M10×1.25 male thread
- Seal material: NBR/PU composite
- Temperature range: -20℃ to 80℃
- Protection rating: IP54
- Weight: 0.95kg ±3%
- Dimensions: 140mm(L) × 32mm(Bore W) × 50mm(Mounting H)
- Stroke tolerance: ±1.5mm
- Max thrust: 201N @0.5MPa
- Repeat accuracy: ±0.5mm
Precision stopper cylinder with dual-position locking mechanism, featuring a hardened stainless steel shaft (HRC 45-50) and anti-rotation guide. The TWG32X10R incorporates a visual position indicator window and torque-adjustable stopper head (3-15Nm range). Requires 5μm filtered air with 1-5 oil mist particles for optimal performance.
- Precision workpiece positioning in CNC rotary tables
- Pallet stop systems in assembly conveyor lines
- Tooling fixture locking in automotive welding stations
- Carton height adjustment in packaging machinery
- PCB board clamping in SMT equipment
Installation protocol:
Maintain perpendicular alignment (±0.5°) to load direction.
For vertical mounting, use auxiliary guide rails. Lubricate every
500km of cumulative stroke travel using ISO VG32 turbine oil.
Avoid side-load forces exceeding 30N.
For cyclic operations >60CPM, install auxiliary cooling fins (accessory code: TWG-AC32).
| Property | Property Value |
|---|---|
| sku | TWG32X10R |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <32 mm> |
| Self-locking Function | Non Self-locking |
| Stroke | <10mm> |
| Blocking Method | Roller Type |
