Airtac TWG Stop Cylinder TWG32X10SR
2、Reinforced piston rod design significantly enhances cylinder's resistance to lateral bending moments;
3、Adjustable mounting height with multiple rod end configurations, optional oil-cushioned shock absorber ensures superior damping performance;
4、Lever-type roller mechanism integrated with self-locking device prevents arm rebound-induced pushback on blocked objects;
5、Multiple series and specifications available to meet diverse industrial automation requirements.
Category: Blocking Cylinder | Brand: AIRTAC | Series: TWG
AirTAC TWG Series Stopper Cylinder TWG32X10SR Technical Details
- Model: TWG32X10SR
- Type: Double-acting with magnetic piston (rodless design)
- Bore size: Ø32 mm
- Stroke: 10 mm (±0.5 mm tolerance)
- Operating pressure: 0.1–0.9 MPa
- Ambient temperature: -20℃ to 80℃
- Cushioning: Adjustable air cushion (both ends)
- Mounting: Standard M5 threaded holes (4x) on two sides
- Port size: M5x0.8 (Rc1/8 adaptor optional)
- Seal material: Heat-resistant NBR (nitrile rubber)
- Repeat accuracy: ±0.2 mm
- Maximum thrust: 230N @ 0.6 MPa
- Weight: 0.82 kg (without accessories)
- Dimensions: 150mm(L) × 40mm(W) × 52mm(H)
- Protection rating: IP67 (wipers included)
- Certification: RoHS compliant
High-precision stopper cylinder engineered for position locking in automated systems. Features anodized aluminum construction with hardened stainless steel guide rails, providing exceptional wear resistance. The integrated magnetic piston enables position feedback when paired with proximity sensors (SM series). Includes anti-rotation mechanism for stable vertical/horizontal operation.
- Conveyor line product positioning gates
- Robotic assembly station workpiece clamping
- CNC machine tool safety interlocks
- Automated packaging system component alignment
- 3D printer bed stabilization mechanisms
Installation guidelines:
Maintain 0.5-1mm clearance between stopper face and target surface.
Lubricate guide rails monthly with ISO VG32 hydraulic oil.
For shock absorption in high-cycle applications (>60 CPM),
install external shock absorbers (ASQ-10 series recommended).
| Property | Property Value |
|---|---|
| sku | TWG32X10SR |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <32 mm> |
| Self-locking Function | Non Self-locking |
| Stroke | <10mm> |
| Blocking Method | Roller Type |
