Airtac TWG Stop Cylinder TWG32X15K
2、Reinforced piston rod design significantly enhances cylinder's resistance to lateral bending moments;
3、Adjustable mounting height with multiple rod end configurations, optional oil-cushioned shock absorber ensures superior damping performance;
4、Lever-type roller mechanism integrated with self-locking device prevents arm rebound-induced pushback on blocked objects;
5、Multiple series and specifications available to meet diverse industrial automation requirements.
Category: Blocking Cylinder | Brand: AIRTAC | Series: TWG
AirTAC TWG Series Stopper Cylinder TWG32X15K Technical Details
- Model: TWG32X15K (Standard Stopper Type)
- Bore size: Ø32mm (±0.1mm tolerance)
- Stroke: 15mm (Fixed mechanical stop)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Cushioning: Adjustable air cushion at both ends
- Mounting style: Front flange MF12 with 4×M5 screws
- Port size: M5×0.8 (Dual ports for air supply)
- Piston material: Aluminum alloy hard anodized
- Rod material: Chrome-plated steel (HRC 45-50)
- Seal type: NBR wear-resistant seals
- Temperature range: -20℃ to +80℃ (-4°F to 176°F)
- Weight: 0.82kg (1.81 lbs) ±3%
- Dimensions: 100mm(L) × 52mm(W) × 52mm(H)
- Rod thread: M10×1.25 (External, for stopper attachment)
- Repeat accuracy: ±0.2mm (Under rated pressure)
High-precision mechanical stop cylinder with dual air cushion control, designed for position locking in automated processes. Features integrated stopper mechanism for positive end-position holding, with chrome-plated rod for corrosion resistance in humid environments. Requires filtered air (5-50μm) with lubrication (ISO VG32 recommended).
- PCB board clamping in SMT assembly lines
- Workpiece positioning in CNC rotary tables
- Tool changer locking in machining centers
- Pallet stoppers in automated warehouses
- Precision alignment in optical component assembly
Installation guidelines:
Mount on rigid flat surface (flatness ≤0.1mm). Adjust cushioning screws
with 0.5-1N·m torque. Lubricate through air ports monthly in continuous
operation. Avoid side loads exceeding 30N.
| Property | Property Value |
|---|---|
| sku | TWG32X15K |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <32 mm> |
| Self-locking Function | Non Self-locking |
| Stroke | <15mm> |
| Blocking Method | Lever Roller Type |
