Airtac TWG Stop Cylinder TWG32X15SR
2、Reinforced piston rod design significantly enhances cylinder's resistance to lateral bending moments;
3、Adjustable mounting height with multiple rod end configurations, optional oil-cushioned shock absorber ensures superior damping performance;
4、Lever-type roller mechanism integrated with self-locking device prevents arm rebound-induced pushback on blocked objects;
5、Multiple series and specifications available to meet diverse industrial automation requirements.
Category: Blocking Cylinder | Brand: AIRTAC | Series: TWG
AirTAC TWG Series Stopper Cylinder TWG32X15SR Technical Details
- Model: TWG32X15SR
- Type: Compact double-acting stopper cylinder
- Bore size: 32mm
- Stroke: 15mm
- Operating pressure: 0.1–0.8 MPa
- Cushioning type: Adjustable pneumatic cushion
- Mounting style: Basic type (no accessories)
- Port size: M5x0.8 (standard Rc1/8 adaptor included)
- Temperature range: -10℃ to 70℃
- Seal material: NBR (nitrile rubber)
- Protection rating: IP40
- Weight: Approximately 0.45kg
- Dimensions: 32mm(W) × 32mm(D) × 68mm(H)
- Rod end thread: M6x1.0 internal thread
- Max thrust: 205N @0.6MPa
- Piston speed: 50–700mm/s
Precision stopper cylinder with integrated mechanical locking mechanism, featuring anodized aluminum construction for corrosion resistance. The TWG32X15SR combines position holding capability with smooth linear motion, using dual-sensor slots (inductive sensor compatible) for position feedback. Requires dry filtered air with 5μm filtration.
- Workpiece positioning in CNC machine tool changers
- Pallet stoppers in automated assembly lines
- Safety interlocks in packaging machinery
- Precision height adjustment in semiconductor handling
- Clamping mechanisms in robotic welding fixtures
Installation guidelines:
Maintain coaxial alignment within 0.2mm tolerance during mounting.
Lubricate with ISO VG32 hydraulic oil if operating below -5℃.
Allow 5mm clearance around cylinder body for heat dissipation.
| Property | Property Value |
|---|---|
| sku | TWG32X15SR |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <32 mm> |
| Self-locking Function | Non Self-locking |
| Stroke | <15mm> |
| Blocking Method | Roller Type |
