Airtac TWH Stop Cylinder TWH25X15SL
2. Reinforced piston rod design significantly enhances impact resistance and operational stability;
3. Heavy-duty construction integrates oil buffer systems or adjustable hydraulic shock absorbers for efficient energy absorption during impact;
4. Lever-type roller mechanism with integrated self-locking device prevents arm rebound and ensures secure object retention;
5. Multiple series and specifications available to accommodate diverse application requirements.
Category: Stopper Cylinders | Brand: AirTAC | Series: TWH
AirTAC TWH Series Stopper Cylinder TWH25X15SL Technical Specifications
- Model: TWH25X15SL
- Type: Compact double-acting stopper cylinder
- Bore size: Ø25mm
- Stroke: 15mm (±1mm)
- Operating pressure: 0.1-0.9 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting types: Basic type (Standard), MF1 front flange, MB1 rear flange
- Port size: M5x0.8 (Rc1/8/NPT1/8 optional)
- Piston speed: 50-800 mm/s
- Temperature range: -20℃ to 80℃
- Material: Aluminum alloy body, NBR seals
- Weight: 0.85kg (bare cylinder)
- Dimensions: 100mm(L) × 34mm(W) × 34mm(H) (retracted state)
- Rod thread: M6x1.0 external thread
- Repeat accuracy: ±0.5mm
- Protection class: IP54 (standard), IP67 (optional)
Precision stopper cylinder with integrated mechanical lock mechanism, featuring a unique dual-diameter piston design (25mm main bore + 12mm rod bore) for high holding force. The chrome-plated piston rod and wear-resistant guide rings ensure smooth operation in high-cycle applications. Requires 5μm filtered air with ISO VG32 lubricator oil mist.
- Pallet stop/release mechanisms in conveyor systems
- Workpiece positioning in CNC machine tool changers
- Precision registration in semiconductor handling equipment
- Safety interlocks in automotive assembly fixtures
- Carton flap control in packaging machinery
Installation guidelines:
Maintain 0.5mm minimum clearance between stopper face and target surface.
Use anti-vibration washers when mounting on moving platforms. Lubricate through
air supply (oil mist 1-2 drops/m³) for optimal seal life. Avoid side-load exceeding 15N.
| Property | Property Value |
|---|---|
| sku | TWH25X15SL |
| Port Size | M5×0.8 |
| Proximity Sensor Thread Type | M5×0.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <25 mm> |
| Self-locking Function | Non Self-locking |
| Stroke | <15mm> |
