Airtac TWH Stop Cylinder TWH25X15SLF
2. Reinforced piston rod design significantly enhances impact resistance and operational stability;
3. Heavy-duty construction integrates oil buffer systems or adjustable hydraulic shock absorbers for efficient energy absorption during impact;
4. Lever-type roller mechanism with integrated self-locking device prevents arm rebound and ensures secure object retention;
5. Multiple series and specifications available to accommodate diverse application requirements.
Category: Stopper Cylinders | Brand: AirTAC | Series: TWH
AirTAC TWH Series Blocking Cylinder TWH25X15SLF Specifications
- Model: TWH25X15SLF
- Type: Compact double-acting blocking cylinder
- Bore size: 25mm
- Stroke: 15mm (±1mm adjustability)
- Operating pressure: 0.05–1.0 MPa
- Piston speed: 50–800 mm/s
- Cushioning: Adjustable rubber buffer
- Mounting type: Front flange (MF1) with side mounting holes
- Rod end: Female thread M10×1.25
- Seal material: Polyurethane (PU) with wear-resistant ring
- Temperature range: -10℃ to 80℃
- Port size: M5×0.8 (standard) with NPT1/8 adaptor option
- Weight: 0.68 kg (with accessories)
- Dimensions: 137mm(L) × 40mm(W) × 40mm(H) (fully retracted)
- Repeat accuracy: ±0.2mm
- Protection rating: IP54 (standard), IP67 optional
Precision-engineered blocking cylinder with anti-rotation mechanism and dual-position sensing slots. Features chrome-plated piston rod with scraper seal for contamination resistance. Optimized for high-cycle applications requiring precise mechanical stops and position holding. Requires 5μm filtered air with ISO VG32 hydraulic oil lubrication (optional oil-free operation).
- PCB conveyor positioning systems
- Robotic arm end-effector stoppers
- Automotive part fixture locking
- Pharmaceutical blister pack indexing
- Bottle capping machine height adjustment
Installation note:
Align guide rails parallel to motion axis within 0.2mm tolerance.
Use locknuts with 1.5Nm torque for mounting. Lubricate every 500km of travel.
| Property | Property Value |
|---|---|
| sku | TWH25X15SLF |
| Port Size | M5×0.8 |
| Proximity Sensor Thread Type | M5×0.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <25 mm> |
| Self-locking Function | Self-locking |
| Stroke | <15mm> |
