Airtac TWH Stop Cylinder TWH32X20KF
2. Reinforced piston rod design significantly enhances impact resistance and operational stability;
3. Heavy-duty construction integrates oil buffer systems or adjustable hydraulic shock absorbers for efficient energy absorption during impact;
4. Lever-type roller mechanism with integrated self-locking device prevents arm rebound and ensures secure object retention;
5. Multiple series and specifications available to accommodate diverse application requirements.
Category: Stopper Cylinders | Brand: AirTAC | Series: TWH
AirTAC TWH Series Stopper Cylinder TWH32X20KF Technical Details
- Model: TWH32X20KF
- Type: Compact profile double-acting stopper cylinder
- Bore size: 32mm
- Stroke: 20mm (adjustable cushion)
- Operating pressure: 0.05-1.0 MPa
- Port size: M5x0.8 (standard) with NPT1/8 adaptor option
- Piston rod material: Hard chrome-plated steel
- Tube material: Anodized aluminum alloy
- Seal type: HNBR seals with wear-resistant guide rings
- Temperature range: -10℃ to 80℃
- Mounting: Front flange (ISO 15552 standard) with side mounting holes
- Cushioning: Adjustable pneumatic cushion (both ends)
- Weight: 0.68kg ±2%
- Dimensions: 132mm(L) × 42mm(W) × 42mm(H)
- Protection rating: IP54 (standard), IP67 optional
- Max lateral load capacity: 15N at full extension
High-precision stopper cylinder with integrated shock absorption, designed for repetitive positioning tasks requiring millimeter-level accuracy. Features dual anti-rotation guides for enhanced lateral stability and optional magnetic piston for position feedback. Requires filtered lubricated air (ISO 8573-1:2010 Class 3.4.2).
- Workpiece positioning in CNC loading systems
- Pallet stop mechanisms in conveyor lines
- Precision alignment in semiconductor handling
- Tooling fixture locking in automotive assembly
- Carton height limitation in packaging machinery
Installation guidelines:
Ensure proper alignment of stopper head with workpiece contact surface.
Recommended maintenance: Relubricate every 500,000 cycles in normal operation.
Use 2-position locking when adjusting stroke length.
| Property | Property Value |
|---|---|
| sku | TWH32X20KF |
| Port Size | PT1/8 |
| Proximity Sensor Thread Type | M5×0.5 |
| Magnet | Non-magnetic |
| Bore Diameter | <32 mm> |
| Self-locking Function | Self-locking |
| Stroke | <20mm> |
