Airtac TWH Stop Cylinder TWH32X20SKF
2. Reinforced piston rod design significantly enhances impact resistance and operational stability;
3. Heavy-duty construction integrates oil buffer systems or adjustable hydraulic shock absorbers for efficient energy absorption during impact;
4. Lever-type roller mechanism with integrated self-locking device prevents arm rebound and ensures secure object retention;
5. Multiple series and specifications available to accommodate diverse application requirements.
Category: Stopper Cylinders | Brand: AirTAC | Series: TWH
AirTAC TWH Series Blocking Cylinder TWH32X20SKF Technical Details
- Model Code: TWH32X20SKF
- Bore Size: 32mm (ISO 6432 standard)
- Stroke: 20mm (±1mm tolerance)
- Operating Pressure: 0.1-0.8 MPa
- Action Type: Double-acting with spring return
- Buffer Type: Adjustable hydraulic cushioning (both ends)
- Mounting Style: Standard MF1 flange mounting (ISO 15552 compatible)
- Port Size: 1/8" NPT (G1/8 optional)
- Temperature Range: -20℃ to +80℃
- Rod Material: Hard chrome-plated steel (HCP)
- Tube Material: Anodized aluminum alloy (AL6063-T5)
- Seal Type: HNBR seals (high nitrile for oil resistance)
- IP Rating: IP54 (dust protected & water spray resistant)
- Weight: 0.52kg ±3% (without accessories)
- Dimensions: 100mm(L) × 32mm(W) × 32mm(H) (stroke excluded)
- Stroke Length Tolerance: +1.0mm/-0mm
- Max Thrust: 235N @ 0.6MPa
- Piston Speed: 50-700mm/s (optimal range)
Precision-engineered blocking cylinder featuring anti-rotation mechanism and integrated guide rail system. The TWH32X20SKF combines high lateral load capacity (up to 15N·m) with smooth linear motion, achieved through precision-ground rod and dual ball bearing guides. Includes magnetic piston for sensor detection (PNP/NPN configurable) and anti-vibration lock nuts.
- Automated conveyor stop/positioning systems
- PCB handling robot end effectors
- Pharmaceutical blister packaging position locks
- Automotive part fixturing during machining
- Bottle capping machine height adjustment
Maintenance advisory:
Lubricate guide rails with ISO VG32 hydraulic oil every 50,000 cycles.
Use shim washers when mounting to prevent parallel misalignment exceeding 0.2mm.
| Property | Property Value |
|---|---|
| sku | TWH32X20SKF |
| Port Size | PT1/8 |
| Proximity Sensor Thread Type | M5×0.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <32 mm> |
| Self-locking Function | Self-locking |
| Stroke | <20mm> |
