Airtac TWH Stop Cylinder TWH32X20SKG
2. Reinforced piston rod design significantly enhances impact resistance and operational stability;
3. Heavy-duty construction integrates oil buffer systems or adjustable hydraulic shock absorbers for efficient energy absorption during impact;
4. Lever-type roller mechanism with integrated self-locking device prevents arm rebound and ensures secure object retention;
5. Multiple series and specifications available to accommodate diverse application requirements.
Category: Stopper Cylinders | Brand: AirTAC | Series: TWH
AirTAC TWH Series Blocking Cylinder TWH32X20SKG Technical Details
- Model: TWH32X20SKG
- Type: Double-acting rodless blocking cylinder
- Bore size: Ø32mm
- Stroke: 20mm (±1mm tolerance)
- Operating pressure: 0.1-0.8 MPa
- Cushioning: Adjustable pneumatic cushion
- Seal material: NBR (Nitrile rubber)
- Temperature range: -10℃ to 70℃
- Mounting style: Side-mount with integrated bracket
- Sensor compatibility: Built-in magnet for reed switch (2-wire)
- Protection rating: IP67 (dust/water resistant)
- Weight: 1.2kg (excluding accessories)
- Dimensions: 150mm(L) × 32mm(W) × 50mm(H)
- Piston rod thread: M8×1.25 external thread
- Max lateral load: 35N at 0.5MPa
- Repeat positioning accuracy: ±0.2mm
High-precision blocking cylinder featuring anti-rotation mechanism and integrated shock absorption. The TWH32X20SKG's compact profile and dual-guide rod design ensure stable linear motion, making it ideal for precision stopping applications in confined spaces. Includes wear-resistant guide bushings and corrosion-resistant anodized aluminum body.
- Conveyor line product positioning systems
- Robotic arm end-effector tooling
- PCB handling equipment stoppers
- Pharmaceutical blister packaging machines
- Automotive part assembly fixtures
Installation guidelines:
Maintain 0.5-1mm clearance between stopper and workpiece surface during setup.
Lubricate with ISO VG32 hydraulic oil during maintenance cycles. Avoid side impact forces exceeding 50N.
| Property | Property Value |
|---|---|
| sku | TWH32X20SKG |
| Port Size | PT1/8 |
| Proximity Sensor Thread Type | M5×0.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <32 mm> |
| Self-locking Function | Non Self-locking |
| Stroke | <20mm> |
