Airtac TWH Stop Cylinder TWH40X30SKF
2. Reinforced piston rod design significantly enhances impact resistance and operational stability;
3. Heavy-duty construction integrates oil buffer systems or adjustable hydraulic shock absorbers for efficient energy absorption during impact;
4. Lever-type roller mechanism with integrated self-locking device prevents arm rebound and ensures secure object retention;
5. Multiple series and specifications available to accommodate diverse application requirements.
Category: Stopper Cylinders | Brand: AirTAC | Series: TWH
AirTAC TWH40X30SKF Stopper Cylinder Specifications
- Model: TWH40X30SKF
- Type: Double-acting rodless blocking cylinder with magnetic piston
- Bore size: 40mm
- Stroke: 30mm (±15mm adjustable)
- Operating pressure: 0.1–0.8 MPa
- Temperature range: -20℃ to 80℃
- Port size: M5x0.8 (standard) / NPT1/8 (optional)
- Piston speed: 50–700 mm/s
- Buffer type: Adjustable rubber cushion
- Sensor compatibility: M9/M12 proximity sensors (2 slots)
- Mounting style: Horizontal/vertical base plate (aluminum alloy)
- Seal material: NBR + PU hybrid seals
- Weight: 1.85 kg (without accessories)
- Dimensions: 198mm(L) × 58mm(W) × 45mm(H) (full extension)
- Protection rating: IP54 (standard) / IP67 (w/ optional wiper)
- Lubrication: Pre-lubricated (Grease-free operation)
High-precision stopper cylinder with position-locking mechanism, featuring dual-channel magnetic sensing and anti-rotation design. The hardened stainless steel guide rail ensures ≤0.05mm repeat positioning accuracy. Integrated shock absorption system reduces impact noise by 15dB compared to standard models.
- Pallet positioning in automated warehouses
- Workpiece alignment in CNC machine loading systems
- Conveyor flow control for packaging lines
- Precision stopping in semiconductor handling robots
- Safety interlocks in automotive assembly stations
Installation note:
Maintain 0.5-1mm clearance between stopper and target surface.
Use vibration-proof nuts (Grade 8.8 or higher) for mounting.
Perform monthly rail lubrication with ISO VG32 hydraulic oil.
| Property | Property Value |
|---|---|
| sku | TWH40X30SKF |
| Port Size | PT1/8 |
| Proximity Sensor Thread Type | M5×0.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <40mm> |
| Self-locking Function | Self-locking |
| Stroke | 30mm |
