Airtac TWH Stop Cylinder TWH40X30SKG
2. Reinforced piston rod design significantly enhances impact resistance and operational stability;
3. Heavy-duty construction integrates oil buffer systems or adjustable hydraulic shock absorbers for efficient energy absorption during impact;
4. Lever-type roller mechanism with integrated self-locking device prevents arm rebound and ensures secure object retention;
5. Multiple series and specifications available to accommodate diverse application requirements.
Category: Stopper Cylinders | Brand: AirTAC | Series: TWH
AirTAC TWH Series Blocking Cylinder TWH40X30SKG Technical Details
- Model: TWH40X30SKG
- Type: Double-acting rodless blocking cylinder
- Bore size: Ø40mm (±0.1mm tolerance)
- Stroke: 30mm (adjustable with stopper)
- Operating pressure: 0.15–0.8 MPa
- Buffer type: Adjustable pneumatic cushioning
- Mounting style: SKG series - front flange with reinforced gussets
- Port size: M5x0.8 (standard) or NPT1/8 (optional)
- Temperature range: -20℃ to 80℃
- Material: Aluminum alloy body (A6063-T5) with chrome-plated piston rod
- Seals: NBR (standard)/PU (optional) wear-resistant rings
- Weight: 1.85kg ±3% (without accessories)
- Dimensions: 200mm(L) × 80mm(W) × 82mm(H) (full extension)
- Repeat accuracy: ±0.2mm
- Maximum lateral load: 120N at cylinder center
- ISO standard: 15552 compliant
Precision-engineered rodless cylinder with integrated mechanical stopper mechanism, featuring dual-position magnetic sensor slots (G-type) for position feedback. The TWH series utilizes a unique T-slot carriage design allowing direct load mounting, with corrosion-resistant anodized surfaces for harsh environments. Requires 5μm filtered compressed air with ISO 8573-1:2010 class 3.4.2 air quality.
- Automated assembly line workpiece positioning
- Palletizing robot end-effector alignment
- CNC machine tool fixture clamping
- Pharmaceutical blister packaging press mechanisms
- Lithium battery production line material handling
Installation guidelines:
Ensure perpendicular alignment within 0.05mm/m using precision level.
Apply Loctite 243 (medium strength) to mounting bolts.
Run 50-100 low-pressure cycles (0.1MPa) before full operation.
| Property | Property Value |
|---|---|
| sku | TWH40X30SKG |
| Port Size | PT1/8 |
| Proximity Sensor Thread Type | M5×0.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <40mm> |
| Self-locking Function | Non Self-locking |
| Stroke | 30mm |
