Airtac TWH Stop Cylinder TWH50X30KF
2. Reinforced piston rod design significantly enhances impact resistance and operational stability;
3. Heavy-duty construction integrates oil buffer systems or adjustable hydraulic shock absorbers for efficient energy absorption during impact;
4. Lever-type roller mechanism with integrated self-locking device prevents arm rebound and ensures secure object retention;
5. Multiple series and specifications available to accommodate diverse application requirements.
Category: Stopper Cylinders | Brand: AirTAC | Series: TWH
AirTAC TWH Series Stopper Cylinder TWH50X30KF Technical Details
- Model: TWH50X30KF
- Type: Double-acting single piston rod stopper cylinder
- Bore size: Ø50mm
- Stroke: 30mm (±1mm tolerance)
- Operating pressure: 0.15–0.8 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion (both ends)
- Piston speed: 50–700 mm/s (optimal range 100–500 mm/s)
- Seal material: NBR (Nitrile rubber)
- Body material: Aluminum alloy (anodized) with CR12MoV piston rod
- Mounting type: Standard flange mounting (KF series)
- Weight: 1.23 kg (excluding accessories)
- Dimensions: 160mm(L) × 50mm(W) × 80mm(H) (retracted position)
- Port thread: M5×0.8 (standard), G1/8 optional
- Lubrication: Pre-lubricated (recommended relubrication every 500km stroke)
- ISO standard: 15552 compliant
High-precision stopper cylinder with integrated mechanical locking mechanism, designed for precision workpiece positioning in automated production lines. Features wear-resistant chromium-plated piston rod and dual-position magnetic sensor slots (sensors not included). The KF variant includes reinforced mounting flanges for vibration resistance.
- Assembly line pallet positioning systems
- Robotic welding fixture clamping
- CNC machine tool workpiece stoppers
- Packaging conveyor flow control gates
- Automotive parts transfer line indexing
Installation guidelines:
Maintain 0.5–1mm clearance between stopper tip and target surface during alignment.
Use locknuts with 12–15 N·m torque for flange mounting. Lubricate through air supply
(ISO VG32 equivalent oil mist, 1 drop/m³ air recommended).
| Property | Property Value |
|---|---|
| sku | TWH50X30KF |
| Port Size | PT1/8 |
| Proximity Sensor Thread Type | M8×1.0 |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Self-locking Function | Self-locking |
| Stroke | 30mm |
