Airtac TWH Stop Cylinder TWH50X30SK
2. Reinforced piston rod design significantly enhances impact resistance and operational stability;
3. Heavy-duty construction integrates oil buffer systems or adjustable hydraulic shock absorbers for efficient energy absorption during impact;
4. Lever-type roller mechanism with integrated self-locking device prevents arm rebound and ensures secure object retention;
5. Multiple series and specifications available to accommodate diverse application requirements.
Category: Stopper Cylinders | Brand: AirTAC | Series: TWH
AirTAC TWH50X30SK Non-Rotating Rod Stopper Cylinder Specifications
- Model: TWH50X30SK
- Type: Double-acting non-rotating rod cylinder with built-in stopper
- Bore size: Ø50mm
- Stroke: 30mm (adjustable cushion)
- Operating pressure: 0.05-1.0 MPa
- Port size: M5x0.8 (G1/8 optional)
- Cushion type: Fixed buffer + adjustable elastic stopper
- Rod material: Hard chrome-plated steel
- Tube material: Aluminum alloy (anodized)
- Seal material: NBR + PU hybrid seals
- Temperature range: -10℃ to 80℃
- Weight: 1.8kg ±5%
- Dimensions: 200mm(L) × 50mm(W) × 50mm(H) (excluding mounting accessories)
- Repeat positioning accuracy: ±0.2mm
- Max lateral load capacity: 150N
- Protection rating: IP54 (standard), IP67 (optional)
- Magnetic switch compatibility: D-A73 series (pre-installed conduit)
Precision stopper cylinder featuring anti-rotation mechanism and dual-stage buffering system. The TWH series incorporates a unique wedge-lock design that provides positive mechanical stopping with zero air consumption during holding phase. Optimized for high-cycle applications with built-in wear compensation through adjustable stopper bolts.
- Pallet positioning in automated storage systems
- Workpiece clamping in CNC rotary tables
- Precision stopping in PCB conveyor lines
- Tooling fixture locking in automotive welding robots
- Carton alignment in packaging machinery
Installation note:
Requires periodic lubrication (ISO VG32) every 500,000 cycles.
Maintain 0.3-0.5mm clearance between stopper face and target surface.
For vertical mounting, use auxiliary guide mechanisms.
| Property | Property Value |
|---|---|
| sku | TWH50X30SK |
| Port Size | PT1/8 |
| Proximity Sensor Thread Type | M8×1.0 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Self-locking Function | Non Self-locking |
| Stroke | 30mm |
