Airtac TWH Stop Cylinder TWH50X30SKF
2. Reinforced piston rod design significantly enhances impact resistance and operational stability;
3. Heavy-duty construction integrates oil buffer systems or adjustable hydraulic shock absorbers for efficient energy absorption during impact;
4. Lever-type roller mechanism with integrated self-locking device prevents arm rebound and ensures secure object retention;
5. Multiple series and specifications available to accommodate diverse application requirements.
Category: Stopper Cylinders | Brand: AirTAC | Series: TWH
AirTAC TWH Series Stopper Cylinder TWH50X30SKF Technical Details
- Model: TWH50X30SKF
- Type: Double-acting stopper cylinder with magnetic piston
- Bore size: Ø50 mm
- Stroke: 30 mm (±1mm tolerance)
- Operating pressure: 0.1–0.8 MPa (14.5–116 psi)
- Cushioning: Adjustable rubber buffer (front/rear)
- Mounting style: Standard foot mount (MF1) with optional flange/axis mounts
- Sensor compatibility: SMC D-A93/D-C73 series magnetic switches (pre-wired option)
- Port size: 1/4" NPT (G1/8 adaptor included)
- Piston rod material: Chrome-plated SCM435 steel
- Cylinder tube: Hard-anodized aluminum alloy
- Operating temperature: -20℃ to 80℃ (-4°F to 176°F)
- Weight: 1.45 kg (3.2 lbs)
- Dimensions: 214mm(L) × 82mm(W) × 82mm(H)
- Protection class: IP54 (dust protected & water resistant)
- Lubrication: Pre-lubed (use ISO VG32 turbine oil if maintenance required)
High-precision industrial stopper cylinder featuring 0.05mm repeat positioning accuracy through hardened guide rods and dual linear bearings. The TWH50X30SKF's anti-rotation design maintains alignment under 500N lateral forces, with PTFE seals ensuring leak-free operation for over 5,000km cumulative travel distance.
- Automotive assembly line part positioning gates
- Pallet stop mechanisms in conveyor sorting systems
- Press machine workpiece retention during stamping
- Robotic welding fixture clamping coordination
- LCD panel handling equipment buffer stops
Installation protocol:
Align cylinder axis within 0.2mm perpendicularity tolerance relative to load direction.
Use locknuts with 25-30 N·m torque on mounting bolts. For vertical installations,
add 10-15% pressure compensation in downward movement calculations.
| Property | Property Value |
|---|---|
| sku | TWH50X30SKF |
| Port Size | PT1/8 |
| Proximity Sensor Thread Type | M8×1.0 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Self-locking Function | Self-locking |
| Stroke | 30mm |
