Airtac TWH Stop Cylinder TWH63X30KF
2. Reinforced piston rod design significantly enhances impact resistance and operational stability;
3. Heavy-duty construction integrates oil buffer systems or adjustable hydraulic shock absorbers for efficient energy absorption during impact;
4. Lever-type roller mechanism with integrated self-locking device prevents arm rebound and ensures secure object retention;
5. Multiple series and specifications available to accommodate diverse application requirements.
Category: Stopper Cylinders | Brand: AirTAC | Series: TWH
AirTAC TWH Series Stopper Cylinder TWH63X30KF Technical Details
- Model: TWH63X30KF
- Type: Double-acting compact stopper cylinder
- Bore size: Ø63mm ±0.1mm tolerance
- Stroke: 30mm (adjustable via mechanical stopper)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Operating medium: Dry air (ISO8573-1:2010 Class 3.4.2)
- Cushioning type: Adjustable pneumatic cushioning
- Mounting style: FA-type square flange with 4×M6 threaded holes
- Body material: Aluminum alloy with hard anodized surface
- Rod material: Chrome-plated steel (Cr > 1μm)
- Seal material: NBR (Nitrile) with wear-resistant ring
- Temperature range: -20℃ to 80℃ (non-freezing conditions)
- Port size: G1/8 (BSPP) dual ports
- Repeat positioning accuracy: ±0.5mm
- Protection rating: IP54 (standard wiper seal)
- Weight: 2.5kg ±3% (without accessories)
- Dimensions: 178mm(L) × 80mm(W) × 80mm(H) (full extension)
High-precision stopper cylinder with integrated shock absorption, designed for precision part positioning in automated production lines. Features dual guide rods for enhanced lateral stability and anti-rotation mechanism. The hardened piston rod surface (HV≥700) ensures extended service life in high-cycle applications.
- Automotive assembly line part positioning gates
- PCB board stopper mechanisms in SMT equipment
- Package dimension verification systems
- Robotic palletizing end-effector positioning
- Pharmaceutical blister packaging index control
Installation guidelines:
Maintain 0.5-1mm clearance between stopper face and target surface during mounting.
Lubricate with ISO VG32 turbine oil before initial operation.
For vertical installations, use optional counterbalance valve (AV-02 accessory).
| Property | Property Value |
|---|---|
| sku | TWH63X30KF |
| Port Size | PT1/4 |
| Proximity Sensor Thread Type | M8×1.0 |
| Magnet | Non-magnetic |
| Bore Diameter | 63mm |
| Self-locking Function | Self-locking |
| Stroke | 30mm |
