Airtac TWH Stop Cylinder TWH63X30SK
2. Reinforced piston rod design significantly enhances impact resistance and operational stability;
3. Heavy-duty construction integrates oil buffer systems or adjustable hydraulic shock absorbers for efficient energy absorption during impact;
4. Lever-type roller mechanism with integrated self-locking device prevents arm rebound and ensures secure object retention;
5. Multiple series and specifications available to accommodate diverse application requirements.
Category: Stopper Cylinders | Brand: AirTAC | Series: TWH
AirTAC TWH Series Stopper Cylinder TWH63X30SK Technical Details
- Model: TWH63X30SK
- Type: Compact profile double-acting stopper cylinder
- Bore size: Ø63mm
- Stroke: 30mm (±1mm tolerance)
- Operating pressure: 0.1–0.8 MPa (14.5–116 PSI)
- Cushioning: Adjustable rubber bumper (both ends)
- Port size: M5x0.8 (standard) / G1/8 optional
- Piston rod material: Chrome-plated SCM435 steel
- Tube material: Anodized aluminum alloy
- Seal type: NBR + PU combination seals
- Temperature range: -20℃ to +80℃
- Lubrication: Pre-lubricated (Grease-free operation)
- Weight: 1.45kg (3.2lbs)
- Dimensions: 130mm(L) × 63mm(W) × 63mm(H)
- Mounting: 2x M6 threaded holes (front/rear)
- Repeat accuracy: ±0.5mm
- Max lateral load: 300N at full extension
High-rigidity stopper cylinder with integrated shock absorption, designed for precision part positioning and flow control in automated lines. Features wear-resistant rod guides and anti-rotation mechanism for stable vertical/horizontal operation. Requires 40μm filtered air with 1-5% oil mist recommended for extended seal life.
- Conveyor line product orientation gates
- Robotic welding fixture positioning locks
- PCB handling machine stopper mechanisms
- Automotive assembly pallet stops
- Packaging machine product counting stations
Installation protocol:
Align stopper face perpendicular to moving objects. Adjust cushioning screws
to 1/2 turn from full tight position for optimal impact absorption. Perform
monthly rod wiper inspection in high-cycle applications (>500 cycles/hour).
| Property | Property Value |
|---|---|
| sku | TWH63X30SK |
| Port Size | PT1/4 |
| Proximity Sensor Thread Type | M8×1.0 |
| Magnet | S-Magnetic |
| Bore Diameter | 63mm |
| Self-locking Function | Non Self-locking |
| Stroke | 30mm |
