Airtac TWH Stop Cylinder TWH63X30SKFG
2. Reinforced piston rod design significantly enhances impact resistance and operational stability;
3. Heavy-duty construction integrates oil buffer systems or adjustable hydraulic shock absorbers for efficient energy absorption during impact;
4. Lever-type roller mechanism with integrated self-locking device prevents arm rebound and ensures secure object retention;
5. Multiple series and specifications available to accommodate diverse application requirements.
Category: Stopper Cylinders | Brand: AirTAC | Series: TWH
AirTAC TWH Series Blocking Cylinder TWH63X30SKFG Technical Details
- Model: TWH63X30SKFG
- Type: Double-acting compact blocking cylinder
- Bore size: Ø63mm
- Stroke: 30mm (customizable 10-300mm)
- Operating pressure: 0.05-1.0 MPa
- Operation method: Pneumatic piston with spring return
- Buffer type: Adjustable rubber cushion (both ends)
- Mounting style: Basic fixed (ISO 15552 flange optional)
- Port size: G1/8 (NPT1/8 adaptor available)
- Temperature range: -20℃ to 80℃
- Material: Aluminum alloy body, CR/NBR seals
- Weight: 1.85kg ±2%
- Dimensions: 160mm(L) × 63mm(W) × 63mm(H)
- Rod thread: M12×1.25 external thread
- Maximum speed: 500mm/s
- Protection rating: IP54 (standard), IP67 optional
High-precision blocking cylinder with integrated mechanical stopper mechanism, featuring dual-position locking capability through pneumatic pressure. The anodized surface treatment provides corrosion resistance in humid environments. Optimized seal geometry ensures ≤0.5mm positioning repeat accuracy.
- Conveyor line workpiece positioning gates
- Robotic welding fixture clamping systems
- CNC machine tool safety interlocks
- Automated packaging material feed control
- Semiconductor wafer handling stages
Installation guidance:
Maintain 0.5-1mm clearance between stopper plates during alignment.
Lubricate with ISO VG32 hydraulic oil before initial operation.
Maximum side load: 15% of axial thrust capacity.
| Property | Property Value |
|---|---|
| sku | TWH63X30SKFG |
| Port Size | PT1/4 |
| Proximity Sensor Thread Type | M8×1.0 |
| Magnet | S-Magnetic |
| Bore Diameter | 63mm |
| Self-locking Function | Self-locking |
| Stroke | 30mm |
