Airtac TWH Stop Cylinder TWH80X40KF
2. Reinforced piston rod design significantly enhances impact resistance and operational stability;
3. Heavy-duty construction integrates oil buffer systems or adjustable hydraulic shock absorbers for efficient energy absorption during impact;
4. Lever-type roller mechanism with integrated self-locking device prevents arm rebound and ensures secure object retention;
5. Multiple series and specifications available to accommodate diverse application requirements.
Category: Stopper Cylinders | Brand: AirTAC | Series: TWH
AirTAC TWH80X40KF Stopper Cylinder Technical Specifications
- Model: TWH80X40KF
- Type: Double-acting rodless blocking cylinder
- Bore size: Ø80mm (ISO standard)
- Stroke: 40mm (±1mm tolerance)
- Operating pressure: 0.1–0.8 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting style: Front flange (KF variant) with 4×M8 threaded holes
- Port size: G1/4 (ISO228/1 standard)
- Material: Aluminum alloy body (A6063-T5), CRMo steel guide rod
- Seal material: NBR (nitrile) with wear-resistant ring
- Weight: 3.5kg (without accessories)
- Dimensions: 200mm(L) × 82mm(W) × 85mm(H)
- Max lateral load: 150N (at full extension)
- Repeat accuracy: ±0.2mm
- Protection rating: IP54 (standard sealing)
High-precision industrial stopper cylinder featuring integrated shock absorption and overload protection. The TWH series' unique wedge-block mechanism ensures zero backlash during workpiece positioning. Optimized flow channels reduce air consumption by 15% compared to conventional models. Requires ISO 8573-1:2010 Class 3 compressed air.
- Automotive assembly line part positioning
- Palletizing robot end-effector braking
- CNC machine tool fixture locking
- Electronics conveyor emergency stop systems
- Packaging machine product alignment gates
Maintenance protocol:
Lubricate guide rail monthly with ISO VG32 turbine oil.
Avoid side-impact loads exceeding 20% of maximum capacity.
Install shock absorber when cycle rate exceeds 120cpm.
| Property | Property Value |
|---|---|
| sku | TWH80X40KF |
| Port Size | PT1/4 |
| Proximity Sensor Thread Type | M8×1.0 |
| Magnet | Non-magnetic |
| Bore Diameter | 80 mm |
| Self-locking Function | Self-locking |
| Stroke | <40mm> |
