Airtac TWQ Stopper Cylinder TWQ20X10C
$33.93
Regular price
$41.43
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TWQ20X10C
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
TWQ Stopper Cylinder
1. Compliant with JIS standards;
2. Reinforced piston rod design effectively enhances impact resistance;
3. Fixed mounting height with multiple rod end configurations. Hydraulic shock absorber option delivers superior cushioning performance;
4. Lever-type roller mechanism incorporates self-locking device to prevent rebound pushback from blocked objects;
5. Comprehensive series and specifications available for diverse application needs.
Category: Stopper Cylinder | Brand: AIRTAC | Series: TWQ
Installation tip:
Maintain 0.5-1mm clearance between stopper face and target surface.
For vertical mounting, use M5×12 mounting screws with Loctite 243.
Lubricate every 500,000 cycles using AirTAC P-1 grease.
1. Compliant with JIS standards;
2. Reinforced piston rod design effectively enhances impact resistance;
3. Fixed mounting height with multiple rod end configurations. Hydraulic shock absorber option delivers superior cushioning performance;
4. Lever-type roller mechanism incorporates self-locking device to prevent rebound pushback from blocked objects;
5. Comprehensive series and specifications available for diverse application needs.
Category: Stopper Cylinder | Brand: AIRTAC | Series: TWQ
AirTAC TWQ Series Stopper Cylinder TWQ20X10C Technical Details
- Model: TWQ20X10C
- Type: Compact linear stopper cylinder (double-acting)
- Bore size: 20mm
- Stroke: 10mm
- Operating pressure: 0.1–0.8 MPa
- Operating temperature: -20℃ to 80℃
- Port thread: 1/8" NPT (G1/8 optional)
- Cushioning: Adjustable pneumatic cushion
- Mounting style: Front flange with 4×M5 threaded holes
- Body material: Anodized aluminum alloy
- Rod material: Stainless steel (SUS304)
- Seal material: Nitrile rubber (NBR)
- Weight: 0.48kg ±2%
- Dimensions: 72mm(L) × 34mm(W) × 34mm(H)
- Repeat accuracy: ±0.2mm
- Max thrust: 62N @0.6MPa
Precision stopper cylinder with integrated shock absorption, designed for high-cycle positioning tasks. Features wear-resistant chromium-plated rod and dust-resistant wiper seal. Requires filtered air (5-40μm) with ISO VG32 turbine oil lubrication (optional).
Common Applications:
- Conveyor line workpiece positioning
- Robotic arm end-of-travel stops
- PCB handling equipment position locking
- Packaging machine product alignment systems
- Automated assembly fixture gates
Installation tip:
Maintain 0.5-1mm clearance between stopper face and target surface.
For vertical mounting, use M5×12 mounting screws with Loctite 243.
Lubricate every 500,000 cycles using AirTAC P-1 grease.
| Property | Property Value |
|---|---|
| sku | TWQ20X10C |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Self-locking Function | Non Self-locking |
| Stroke | <10mm> |
| Blocking Method | Round Type |
