Airtac TWQ Stopper Cylinder TWQ20X15C
1. Compliant with JIS standards;
2. Reinforced piston rod design effectively enhances impact resistance;
3. Fixed mounting height with multiple rod end configurations. Hydraulic shock absorber option delivers superior cushioning performance;
4. Lever-type roller mechanism incorporates self-locking device to prevent rebound pushback from blocked objects;
5. Comprehensive series and specifications available for diverse application needs.
Category: Stopper Cylinder | Brand: AIRTAC | Series: TWQ
AirTAC TWQ Series Blocking Cylinder TWQ20X15C Specifications
- Model: TWQ20X15C
- Type: Double-acting compact blocking cylinder
- Bore size: 20mm
- Stroke: 15mm (±1mm tolerance)
- Operating pressure: 0.1–0.8 MPa
- Cushioning type: Adjustable pneumatic cushioning
- Mounting style: Foot-mounted (optional flange/clevis kits)
- Port size: M5x0.8 (standard) or NPT1/8 (optional)
- Temperature range: -20℃ to 80℃
- Material: Aluminum alloy body, NBR seals
- Weight: 0.82kg (excluding accessories)
- Dimensions: 100mm(L) × 34mm(W) × 34mm(H) (basic length without stroke)
- Rod thread: M6x1.0 external thread
- Max thrust: 62.8N @0.6MPa
- Repeat positioning accuracy: ±0.2mm
High-precision blocking cylinder with integrated mechanical lock mechanism, featuring wear-resistant chromium-plated piston rod and anti-rotation guide. Designed for precision stopping applications requiring position retention under residual pressure. Includes magnetic sensor slots (NPN/PNP compatible) for position feedback.
- Conveyor line workpiece positioning
- Robotic arm end-effector braking
- Press tooling safety interlocks
- PCB handling equipment stoppers
- Automated assembly line indexing
Installation note:
Lubricate with ISO VG32 hydraulic oil before operation. For vertical mounting,
use auxiliary support brackets. Maintain 0.3-0.5mm clearance between blocking
arm and target surface during alignment.
| Property | Property Value |
|---|---|
| sku | TWQ20X15C |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Self-locking Function | Non Self-locking |
| Stroke | <15mm> |
| Blocking Method | Round Type |
