Airtac TWQ Stopper Cylinder TWQ20X15R
1. Compliant with JIS standards;
2. Reinforced piston rod design effectively enhances impact resistance;
3. Fixed mounting height with multiple rod end configurations. Hydraulic shock absorber option delivers superior cushioning performance;
4. Lever-type roller mechanism incorporates self-locking device to prevent rebound pushback from blocked objects;
5. Comprehensive series and specifications available for diverse application needs.
Category: Stopper Cylinder | Brand: AIRTAC | Series: TWQ
AirTAC TWQ Series Blocking Cylinder TWQ20X15R Technical Details
- Model Code: TWQ20X15R
- Type: Compact rodless blocking cylinder (rotary clamp type)
- Bore size: Ø20 mm
- Stroke: 15 mm ±0.5
- Operating pressure: 0.1–0.9 MPa
- Max thrust: 63 N at 0.6 MPa
- Buffer type: Adjustable pneumatic cushioning
- Mounting style: Standard base mounting with M4 threaded holes
- Port size: M5x0.8 (dual ports for push/pull operation)
- Temperature range: -10℃ to 80℃
- Material: Aluminum alloy body, CRCA steel slide rail
- Seal type: HNBR seals with wear-resistant guide rings
- Weight: 0.48 kg ±3%
- Dimensions: 98mm(L) × 34mm(W) × 34mm(H)
- Repeat accuracy: ±0.2mm
- Protection class: IP54 (standard dust/moisture resistance)
Precision linear blocking mechanism combining vertical clamping and horizontal positioning. Features dual-action locking via pneumatic pressure with mechanical fail-safe position memory. The T-slot design allows direct mounting of workpieces or tooling plates. Requires filtered air (5-40μm) with optional lubricator (ISO VG32 recommended).
- PCB conveyor pallet positioning systems
- Automotive part fixture locking during machining
- Robotic arm end-effector quick-change modules
- Pharmaceutical vial sorting line stoppers
- 3C product assembly precision alignment
Installation protocol:
Maintain 0.05-0.1mm clearance between cylinder base and mounting surface.
Lubricate guide rail monthly with ISO VG68 slideway oil. Avoid side-load forces exceeding 15N.
| Property | Property Value |
|---|---|
| sku | TWQ20X15R |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Self-locking Function | Non Self-locking |
| Stroke | <15mm> |
| Blocking Method | Roller Type |
