Airtac TWQ Stopper Cylinder TWQ20X15SB
1. Compliant with JIS standards;
2. Reinforced piston rod design effectively enhances impact resistance;
3. Fixed mounting height with multiple rod end configurations. Hydraulic shock absorber option delivers superior cushioning performance;
4. Lever-type roller mechanism incorporates self-locking device to prevent rebound pushback from blocked objects;
5. Comprehensive series and specifications available for diverse application needs.
Category: Stopper Cylinder | Brand: AIRTAC | Series: TWQ
AirTAC TWQ Series Blocking Cylinder TWQ20X15SB Technical Details
- Model: TWQ20X15SB
- Type: Compact double-acting blocking cylinder with magnetic piston
- Bore size: 20mm
- Stroke: 15mm (±1mm tolerance)
- Operating pressure: 0.05-1.0 MPa
- Operating medium: Filtered air (40μm+ filtration required)
- Port thread: M5x0.8 (standard) / G1/8 optional
- Cushion type: Adjustable pneumatic cushioning
- Piston speed: 50-800 mm/s
- Ambient temperature: -10℃ to 60℃ (NBR seals)
- Repeat positioning accuracy: ±0.2mm
- Body material: Aluminum alloy (hard anodized)
- Rod material: Stainless steel (SUS304)
- Weight: 0.48kg (excluding accessories)
- Dimensions:
- Body length: 76mm
- Extended length: 76 + 15 = 91mm
- Mounting width: 32mm
- Height (with rail): 42mm
- ISO standard: 15552 (compliant)
- Protection class: IP54 (standard sealing)
Precision-engineered blocking cylinder featuring dual-position magnetic detection slots for sensor integration. The TWQ20X15SB combines high lateral load capacity (up to 30N) with compact dimensions, utilizing a chromium-plated piston rod for enhanced corrosion resistance. Requires 1-3μm oil mist lubrication for optimal performance in high-cycle applications.
- PCB board positioning in SMT assembly lines
- Workpiece stopping mechanisms in CNC rotary tables
- Carton alignment systems in packaging machinery
- Precision clamping in automotive welding jigs
- Component indexing in pharmaceutical blister packaging
Installation guidelines:
Mount using M4x8mm flat-head screws (max torque 1.2N·m). Maintain 0.5-1mm clearance between stopper and workpiece. Lubricate every 5,000km operation or 3 months. Avoid side-load exceeding 15% of axial thrust capacity.
| Property | Property Value |
|---|---|
| sku | TWQ20X15SB |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Self-locking Function | Non Self-locking |
| Stroke | <15mm> |
| Blocking Method | Flat Cylinder |
