Airtac TWQ Stopper Cylinder TWQ20X15SC
1. Compliant with JIS standards;
2. Reinforced piston rod design effectively enhances impact resistance;
3. Fixed mounting height with multiple rod end configurations. Hydraulic shock absorber option delivers superior cushioning performance;
4. Lever-type roller mechanism incorporates self-locking device to prevent rebound pushback from blocked objects;
5. Comprehensive series and specifications available for diverse application needs.
Category: Stopper Cylinder | Brand: AIRTAC | Series: TWQ
AirTAC TWQ20X15SC Stopper Cylinder Technical Details
- Model: TWQ20X15SC
- Type: Compact double-acting stopping cylinder
- Bore size: 20mm
- Stroke: 15mm
- Operating pressure: 0.05–1.0 MPa
- Cushioning: Adjustable rubber buffer
- Mounting style: Standard base mounting with M4 threaded holes
- Port size: M5x0.8 (dual ports for forward/return action)
- Temperature range: -10℃ to 80℃
- Rod material: Stainless steel (SUS304)
- Cylinder body: Anodized aluminum alloy
- Seal material: NBR (nitrile rubber)
- Weight: 0.38kg ±5%
- Dimensions: 130mm(L) × 34mm(W) × 34mm(H)
- Repeat accuracy: ±0.2mm
- Magnetic switch compatibility: D-A93 series (optional)
High-precision stopping cylinder with integrated shock absorption, featuring a reinforced rod end for impact resistance. The TWQ20X15SC's compact profile enables installation in confined spaces while maintaining 20N holding force capacity. Includes wear-resistant guide bushings and anti-rotation shaft design for stable operation in high-cycle applications (up to 1.5 million cycles). Requires ISO 8573-1:2010 Class 3 compressed air.
- Position verification in conveyor sorting systems
- Workpiece alignment in CNC machine tool loaders
- Carton positioning for automated packaging lines
- Pallet stop mechanism in AS/RS warehouses
- Precision part clamping during robotic assembly
Installation guidelines:
Ensure piston rod remains perpendicular to workpiece surface (±2° tolerance).
Apply silicone-based grease (ISO VG32 equivalent) monthly.
Maintain 0.5mm minimum clearance between stopper and target surface during adjustment.
| Property | Property Value |
|---|---|
| sku | TWQ20X15SC |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Self-locking Function | Non Self-locking |
| Stroke | <15mm> |
| Blocking Method | Round Type |
