Airtac TWQ Stopper Cylinder TWQ20X20C
1. Compliant with JIS standards;
2. Reinforced piston rod design effectively enhances impact resistance;
3. Fixed mounting height with multiple rod end configurations. Hydraulic shock absorber option delivers superior cushioning performance;
4. Lever-type roller mechanism incorporates self-locking device to prevent rebound pushback from blocked objects;
5. Comprehensive series and specifications available for diverse application needs.
Category: Stopper Cylinder | Brand: AIRTAC | Series: TWQ
AirTAC TWQ20X20C Stopper Cylinder Technical Details
- Model: TWQ20X20C
- Type: Compact double-acting stopper cylinder
- Bore size: 20mm
- Stroke: 20mm (standard)
- Operating pressure: 0.1–0.8 MPa
- Temperature range: -20℃ to 80℃
- Buffer type: Adjustable pneumatic cushioning
- Mounting style: Foot/Flange (optional accessories)
- Material: Aluminum alloy barrel, hardened steel piston rod
- Seal material: NBR (Nitrile rubber)
- Port size: 1/8" NPT (G1/8 optional)
- Protection class: IP65
- Weight: 0.8kg ±5%
- Dimensions: 200mm(L) × 40mm(W) × 40mm(H)
- ISO standard: 6432 compliant
Precision-engineered stopper cylinder with integrated shock absorption, designed for high-cycle positioning and workpiece stopping in automated systems. Features chrome-plated piston rod with wear-resistant scraper ring for extended service life. Optimized flow path design enables rapid response (≤0.3s actuation time).
- Conveyor line product positioning systems
- Robotic arm end-effector tooling
- CNC machine part clamping mechanisms
- Automotive assembly station stoppers
- Packaging machine gate control
Installation guidelines:
Maintain 0.05mm maximum lateral misalignment during mounting.
Use M5 mounting screws with 4.4Nm torque specification.
Lubricate with ISO VG32 hydraulic oil before initial operation.
- Filtered air supply (5μm or finer)
- Relative humidity below 85% (non-condensing)
- Maximum lateral load: 15N at full extension
- Re-lubrication interval: 3 million cycles
| Property | Property Value |
|---|---|
| sku | TWQ20X20C |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Self-locking Function | Non Self-locking |
| Stroke | <20mm> |
| Blocking Method | Round Type |
