Airtac TWQ Stopper Cylinder TWQ20X20R
1. Compliant with JIS standards;
2. Reinforced piston rod design effectively enhances impact resistance;
3. Fixed mounting height with multiple rod end configurations. Hydraulic shock absorber option delivers superior cushioning performance;
4. Lever-type roller mechanism incorporates self-locking device to prevent rebound pushback from blocked objects;
5. Comprehensive series and specifications available for diverse application needs.
Category: Stopper Cylinder | Brand: AIRTAC | Series: TWQ
AirTAC TWQ Series Blocking Cylinder TWQ20X20R Technical Details
- Model: TWQ20X20R
- Type: Compact rodless blocking cylinder (dual function: pushing + clamping)
- Bore size: 20mm
- Stroke: 20mm (±1mm adjustable)
- Operating pressure: 0.05–0.9 MPa
- Cushion type: Rubber buffer + adjustable damping
- Mounting style: Standard base mount (M4 threaded holes)
- Port size: M5x0.8 (dual ports for push/return action)
- Temperature range: -10℃ to 80℃
- Body material: Anodized aluminum alloy
- Piston rod: Stainless steel SUS304
- Seal material: NBR (nitrile rubber)
- Protection rating: IP40 (dust protected)
- Weight: 0.68kg ±2%
- Dimensions: 120mm(L) × 32mm(W) × 32mm(H) (excluding mounting accessories)
- Max thrust force: 62.8N at 0.5MPa
- Repeat positioning accuracy: ±0.1mm
High-precision linear blocking cylinder designed for precision positioning and workpiece clamping in confined spaces. Features dual-action control with integrated magnetic sensor slots (non-inductive model as standard). The TWQ series utilizes a unique T-slot guide mechanism for enhanced lateral load resistance, achieving 2x longer service life compared to conventional rodless cylinders. Requires 5μm filtered dry air with ISO VG32 turbine oil mist lubrication (1 drop/cycle recommended).
- PCB board positioning in SMT assembly lines
- Glass panel clamping for LCD manufacturing
- Precision part ejection in die-casting machines
- Carton box alignment in packaging systems
- Semiconductor wafer handling robots
Installation guidelines:
Maintain horizontal orientation tolerance within ±2°. Lubricate guide rails every 500km of travel.
Use shock absorbers when cycle rate exceeds 120cpm. Minimum 3mm clearance required for sensor cables.
| Property | Property Value |
|---|---|
| sku | TWQ20X20R |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Self-locking Function | Non Self-locking |
| Stroke | <20mm> |
| Blocking Method | Roller Type |
