Airtac UE95A PU Pneumatic Hose UE95A032020020MGA
2、High elasticity: Minimal bending radius enables tight-space routing;
3、Anti-kinking properties: Superior resistance to coiling compared to conventional plastic tubes;
4、Exceptional shape memory: Withstands repeated expansion/contraction cycles;
5、Abrasion resistance: Extended service life in wear-prone environments;
6、Low gas permeability: Reduces leakage and contamination risks;
7、Excellent solvent resistance: Eliminates environmental pollution from fluid migration;
8、Minimal compression set: Maintains critical physical properties under load;
9、Media compatibility: Air/Water.
Category: Compressed Air Tubing , Brand: Airtac , Series: UE95A
AirTAC UE95A032020020MGA PU Pneumatic Hose Detailed Specifications
- Full model: UE95A032020020MGA
- Series: UE95A SuperFlex PU Tubing
- Inner diameter: 3.2mm (±0.2mm)
- Outer diameter: 6.0mm (±0.3mm)
- Material: Polyurethane (PU) with spiral reinforcement
- Temperature range: -20℃ to +70℃ (continuous use)
- Max working pressure: 1.0 MPa (10 bar)
- Burst pressure: ≥4.0 MPa
- Certification: RoHS compliant, FDA-grade material option available
- Color: Standard blue (custom colors: clear/black/orange optional)
- Coil length: 20 meters (standard cut length: 1M/5M/10M/20M)
- Min bending radius: 15mm (at 20℃)
- Weight per meter: 0.02kg/m (±5%)
- Total weight (20M coil): 0.4kg (excluding packaging)
- Coil dimensions: 200mm (W) × 200mm (D) × 200mm (H)
- Surface resistance: ≤10^9 Ω (anti-static version available)
- Oil resistance: Excellent (compatible with ISO VG32 hydraulic oil)
Premium spiral-reinforced polyurethane hose featuring 360° bend protection and memory-free coiling. The staggered helix structure prevents kinking while maintaining exceptional flexibility. Special anti-abrasion formulation resists particle embedding, making it ideal for cleanroom-adjacent applications. Inner surface smoothness (Ra≤0.8μm) ensures minimal pressure drop.
- Robotic arm end-effector pneumatic connections
- Food processing equipment with frequent tooling changes
- Medical device pneumatic systems requiring USP Class VI compliance
- High-cycle automation with continuous flexing (up to 2 million bend cycles @R15mm)
- Low-temperature environments like cold storage logistics systems
Installation protocol:
Always maintain 10% extra length for thermal expansion. Use hose cutters (not knives)
for clean ends. For coiled applications, unwind completely before pressure testing.
Maximum lateral pull force: 15N during routing.
| Property | Property Value |
|---|---|
| sku | UE95A032020020MGA |
| Inner Diameter | <2.0mm> |
| Wall Thickness | <0.60mm> |
| Outer Diameter | 3.2mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature (°C): -40 to 70 |
| Bend Radius | <8mm> |
| Length per Roll | M20 |
| Color | Gray |
