Airtac UE95A PU Pneumatic Hose UE95A032020020MY
$8.60
Regular price
$16.10
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
UE95A032020020MY
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Thermoplastic Polyurethane (TPU) material, ROHS-compliant environmental standards;
2、High elasticity: Minimal bending radius enables tight-space routing;
3、Anti-kinking properties: Superior resistance to coiling compared to conventional plastic tubes;
4、Exceptional shape memory: Withstands repeated expansion/contraction cycles;
5、Abrasion resistance: Extended service life in wear-prone environments;
6、Low gas permeability: Reduces leakage and contamination risks;
7、Excellent solvent resistance: Eliminates environmental pollution from fluid migration;
8、Minimal compression set: Maintains critical physical properties under load;
9、Media compatibility: Air/Water.
Category: Compressed Air Tubing , Brand: Airtac , Series: UE95A
Installation guidelines:
Maintain 10% extra length for moving parts, avoid sharp edges. Use PCL-06 series
push-to-connect fittings for leak-proof connections. Store coils vertically
in UV-protected areas below 40℃.
2、High elasticity: Minimal bending radius enables tight-space routing;
3、Anti-kinking properties: Superior resistance to coiling compared to conventional plastic tubes;
4、Exceptional shape memory: Withstands repeated expansion/contraction cycles;
5、Abrasion resistance: Extended service life in wear-prone environments;
6、Low gas permeability: Reduces leakage and contamination risks;
7、Excellent solvent resistance: Eliminates environmental pollution from fluid migration;
8、Minimal compression set: Maintains critical physical properties under load;
9、Media compatibility: Air/Water.
Category: Compressed Air Tubing , Brand: Airtac , Series: UE95A
AirTAC UE95A PU Pneumatic Hose UE95A032020020MY Full Specifications
- Model: UE95A032020020MY
- Material: Polyurethane (PU) reinforced with polyester braid
- Inner Diameter: 3.2 mm ±0.1mm
- Outer Diameter: 6.0 mm ±0.2mm
- Standard Length: 20 meters per coil
- Weight: 0.08 kg/m (1.6 kg per 20m coil)
- Coil Dimensions: 340mm(W) × 340mm(D) × 120mm(H)
- Operating Pressure: 0.3-1.0 MPa (3-10 bar)
- Burst Pressure: ≥4.0 MPa
- Temperature Range: -20℃ to +70℃ (instantaneous peak 90℃)
- Bending Radius: 30mm minimum (dynamic), 15mm (static)
- Color: Semi-transparent blue with yellow tracer line
- Certification: RoHS compliant, REACH SVHC-free
- Tube Hardness: 85±5 Shore A
- Elongation at Break: ≥250%
Ultra-flexible polyurethane hose with exceptional kink resistance and memory-free performance. Features an embedded anti-static copper wire (surface resistance ≤10⁶Ω) for explosive environments. The smooth inner bore minimizes pressure drop, while the abrasion-resistant outer layer withstands 500,000+ bending cycles.
Industrial Applications:
- Robotic end-effector tooling in automotive assembly lines
- High-cycle pneumatic grippers in electronics manufacturing
- Medical device pneumatic systems (non-sterile areas)
- Food processing machinery (compatible with FDA-grade air)
- CNC machine tool auto-chuck mechanisms
Installation guidelines:
Maintain 10% extra length for moving parts, avoid sharp edges. Use PCL-06 series
push-to-connect fittings for leak-proof connections. Store coils vertically
in UV-protected areas below 40℃.
Chemical Resistance:
Excellent resistance to oils, greases, and weak acids. Avoid prolonged exposure to
ketones, concentrated acids, and chlorinated solvents. Not suitable for hydraulic fluids
containing ester additives.
| Property | Property Value |
|---|---|
| sku | UE95A032020020MY |
| Inner Diameter | <2.0mm> |
| Wall Thickness | <0.60mm> |
| Outer Diameter | 3.2mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature (°C): -40 to 70 |
| Bend Radius | <8mm> |
| Length per Roll | M20 |
| Color | Yellow |
