Airtac X-ABC Connector - Locknut Straight Terminal X-ABC1002A
$4.20
Regular price
$11.70
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-ABC1002A
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-ABC1002A Straight Through Terminal with Locknut Specifications
- Model: X-ABC1002A
- Type: Push-to-connect straight terminal (one-touch fitting)
- Material: Brass with nickel plating
- Thread Standard: PT1/8 (BSPP)
- Seal Material: NBR (Nitrile) rubber
- Operating Pressure: 0.5-1.5 MPa
- Temperature Range: -20℃ to 80℃
- Tightening Torque: 1.2-1.5 N·m (recommended)
- Tube Compatibility: Φ6mm (1/4") OD polyurethane/nylon tubing
- Weight: 52g ±2g
- Dimensions: 30mm(L) × 20mm(W) × 20mm(H)
- IP Rating: IP54 (standard sealing)
- Vibration Resistance: ≤10Hz, amplitude ≤1mm
High-flow pneumatic connector featuring dual-lock mechanism (thread + collet grip) for secure tubing connections. The 360° rotatable design enables flexible piping layouts in confined spaces. Includes built-in O-ring for positive sealing and anti-vibration washers to prevent loosening.
Typical Applications:
- Pneumatic cylinder port connections
- Modular automation platforms (Festo-type systems)
- Medical gas line distribution
- Packaging machine tooling interfaces
- Semiconductor equipment air supply
Installation guide:
Insert tube until "click" sound is heard (full 15mm insertion depth required).
For maintenance, press and hold the collet release collar while withdrawing tubing.
Apply thread sealant on male threads only - avoid contaminating the collet mechanism.
