Airtac X-ABC Connector - Locknut Straight Terminal X-ABC1202A
AirTAC X-ABC Series Connector - Locknut Straight Terminal X-ABC1202A Specifications
- Model: X-ABC1202A
- Type: Locknut Straight Terminal (Male Thread)
- Body Material: PA66+30% GF (Glass Fiber Reinforced)
- Thread Specification: M12×1.5
- Applicable Tube OD: Ø12mm (Flexible Pneumatic Tubing)
- Pressure Rating: 0.05-1.0 MPa
- Temperature Range: -20℃ to +80℃
- Seal Material: HNBR (Hydrogenated Nitrile Rubber)
- Weight: 28g ±1g
- Dimensions: 35mm(L) × 25mm(W) × 24mm(H)
- Thread Engagement Depth: 10mm
- Vibration Resistance: ≤5Hz/1.5mm amplitude
- Certification: RoHS compliant
High-density polymer terminal connector with anti-vibration locknut design, featuring color-coded sealing rings (blue HNBR) for quick visual inspection. The 45° angled compression sleeve ensures leak-free connections during repeated assembly/disassembly. Compatible with ISO 15407-1 standard tubing.
- Modular pneumatic manifold block installations
- Robotic end-effector tooling air supply lines
- PLC-controlled valve island interfaces
- Medical device pneumatic control cabinets
- Food processing equipment (dry air systems)
Installation protocol:
Hand-tighten locknut until resistance is felt, then apply 1/4 turn with wrench.
Maximum torque 2.5N·m. Replace sealing ring every 5,000 connection cycles
or when visible compression set exceeds 15%.
| Property | Property Value |
|---|---|
| sku | X-ABC1202A |
