Airtac X-ABC Connector - Locknut Straight Terminal X-ABC1203
$4.82
Regular price
$12.32
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-ABC1203
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-ABC1203 Straight Through Terminal with Locknut Specifications
- Model: X-ABC1203
- Type: Push-in straight terminal with locknut
- Material: Brass (nickel-plated) / PBT housing
- Thread Standard: PT1/8 (BSPP) / NPT1/8 optional
- Seal Material: NBR (Nitrile) / FKM (Fluorocarbon) optional
- Operating Pressure: 0.5-1.6 MPa
- Temperature Range: -5℃ to +60℃ (with NBR seal)
- Flow Rate: 350 NL/min (at 0.5 MPa)
- Installation Torque: 1.5-2 Nm (brass) / 0.8-1.2 Nm (PBT)
- Tube Compatibility: Ø4mm (1/8") soft nylon/polyurethane tubes
- Weight: 18g ±0.5g
- Dimensions: 20mm(L) × 16mm(W) × 16mm(H)
- Color Code: Blue body with silver locknut
- Certification: RoHS compliant
- Max Leakage: ≤0.1 NL/min (under 0.5 MPa)
High-density sealing terminal with 360° rotatable locknut, designed for stable pneumatic connections in vibration-prone environments. Features double O-ring structure and anti-pullout sleeve for secure tube retention. Corrosion-resistant plating ensures 500,000+ insertion cycles.
Typical Applications:
- Modular pneumatic manifold assemblies
- Robotic arm end-effector air supply
- CNC machine tool pneumatic circuits
- Food processing equipment (FKM seal version)
- Laboratory analytical instrument gas lines
Installation guide:
Insert tube until audible click, then hand-tighten locknut clockwise.
For metal surfaces, apply 2-3 wraps of PTFE tape on threads.
Max reconnection attempts: 3 times per port.
| Property | Property Value |
|---|---|
| sku | X-ABC1203 |
