Airtac X-ABC Connector - Locknut Straight Terminal X-ABC601
AirTAC X-ABC601 Connector-Locknut Straight Terminal Specifications
- Model: X-ABC601
- Type: Straight terminal with locknut (threaded joint)
- Material: Brass with nickel plating
- Thread Standard: M5×0.8 (metric fine thread)
- Operating Pressure: 0.2–1.0 MPa
- Temperature Range: -20℃ to 80℃
- Seal Material: NBR (Nitrile Rubber)
- IP Rating: IP40 (dust protected)
- Certification: RoHS compliant
- Weight: 28g ±1g
- Dimensions: 50mm(L) × 20mm(W) × 20mm(H)
- Torque Specification: 0.8–1.2 N·m
- Surface Roughness: Ra ≤3.2μm
High-density precision connector featuring dual-seal structure with anti-vibration locknut. The chrome-plated brass body ensures corrosion resistance in humid environments. Optimized flow path design reduces pressure drop by 15% compared to standard terminals.
- Pneumatic cylinder exhaust port termination
- Modular pneumatic manifold systems
- CNC machine tool air circuit distribution
- Food-grade equipment requiring quick-disconnect
- Laboratory analytical instrument gas lines
Installation protocol:
Use two wrenches during assembly – hold base fitting with 12mm wrench while tightening locknut with 17mm wrench. Apply thread sealant only on male threads, avoiding contact with sealing surfaces. Maximum angular deviation: ±3° from axis.
⚠️ Critical: Do NOT exceed 1.5MPa pressure. Avoid using with incompatible fluids (compatible with air, inert gases, and light oils). Replace seals every 5,000 operating hours or 2 years (whichever comes first).
| Property | Property Value |
|---|---|
| sku | X-ABC601 |
