Airtac X-ABC Connector - Locknut Straight Terminal X-ABC602
$3.58
Regular price
$11.08
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-ABC602
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-ABC602 Connector-Locknut Straight Terminal Specifications
- Model: X-ABC602
- Type: Straight thread-locknut terminal
- Body material: Nickel-plated brass (C3604)
- Seal material: NBR (Nitrile rubber)
- Thread standard: Metric (M5×0.8)
- Alternative thread: UNF 10-32 available
- Max working pressure: 1.0 MPa (145 psi)
- Temperature range: -20℃ to 80℃
- Proof pressure: 1.5 MPa
- Burst pressure: 3.0 MPa
- Weight: 8.5g ±0.3g (0.019 lb)
- Dimensions: 16mm(L) × 12mm(W) × 10mm(H) (0.63"×0.47"×0.39")
- Surface roughness: Ra ≤3.2μm
- Torque specification: 0.7-1.2 N·m (6.2-10.6 lb-in)
- Compatibility: Works with PU/Nylon tubing (ID 2-4mm)
- Certification: RoHS compliant
High-density forged brass terminal with dual sealing structure (radial O-ring + axial face seal). Features anti-vibration locknut design with 6mm hex wrench flat. Electroplated surface prevents oxidation in humid environments. Rated for 500,000+ insertion cycles.
Typical Applications:
- Pneumatic manifold block connections
- Modular assembly in automation equipment
- Sensor/valve port extensions
- Vacuum system junctions
- Medical gas line distribution
- Robotic end-effector pneumatic routing
Installation protocol:
Apply thread sealant only on male threads (not on sealing surfaces).
Use backup wrench during tightening to prevent tube torsion.
Maximum 120° rotation after initial contact with sealing surface.
Warning:
Not compatible with ester-based lubricants.
Always perform pressure test at 1.25× working pressure after installation.
Replace if hex flats show visible deformation.
| Property | Property Value |
|---|---|
| sku | X-ABC602 |
