AirTAC X-ABD0102 Male-Female Straight Threaded Connector Specifications
- Model: X-ABD0102
- Type: Male-Female straight through connector
- Thread standard: Metric parallel thread (ISO 1179)
- Male thread size: G1/8 (9.728mm OD)
- Female thread size: G1/8 (9.728mm ID)
- Material: Brass (CuZn39Pb3) with nickel plating
- Max working pressure: 1.5 MPa (217 psi)
- Temperature range: -20℃ to 120℃
- Seal type: NBR O-ring (replaceable)
- Torque resistance: ≤30 N·m
- Certifications: RoHS compliant
- Weight: 18.5±0.5g
- Dimensions: 24mm(L) × 12.5mm(W) × 12.5mm(H)
A bidirectional flow connector with corrosion-resistant nickel plating, designed for leak-free transitions between male and female threaded ports in pneumatic systems. Features 360° rotatable male end for easy alignment during installation. Compatible with air, water, and inert gases.
Typical Applications:
- Pneumatic cylinder port extensions
- Modular assembly in automation equipment
- Branch line connections in compressed air systems
- Vacuum line fittings for packaging machinery
- Sensor mounting interfaces
Installation note:
Apply 1.5-2 wraps of PTFE tape on male threads (clockwise winding).
Avoid overtightening - recommended torque 12-15 N·m.
Replace O-ring every 5,000 cycles in high-vibration environments.
