Airtac X-ABD Male-Female Straight Thread Connector X-ABD0103
$3.43
Regular price
$10.93
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-ABD0103
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-ABD0103 Internal/External Thread Straight Fitting Specifications
- Model: X-ABD0103
- Type: Metric BSPP/BSPT dual-threaded straight connector
- Internal thread: G1/8 (BSPP 28 threads/inch)
- External thread: R1/8 (BSPT 28 threads/inch)
- Material: Lead-free brass CW617N with nickel plating
- Seal type: Integrated O-ring (NBR rubber)
- Pressure rating: 0.05-1.5 MPa (7-217 psi)
- Temperature range: -20℃ to 120℃ (continuous)
- Proof pressure: 3.0 MPa
- Burst pressure: ≥6.0 MPa
- Surface hardness: HV200-250
- Weight: 18.5±0.5g
- Dimensions: 30mm(L) × 10mm(Dia) × 12.5mm(Hex)
- Standards: ISO 1179-1, RoHS compliant
Precision-machined transition fitting for hybrid pneumatic systems requiring BSPP (parallel) to BSPT (tapered) thread conversion. Features anti-vibration knurling and 360° rotatable sealing surface. The nickel coating provides enhanced corrosion resistance in humid environments.
Typical Applications:
- Retrofitting British-standard equipment to ISO pneumatic lines
- Compressed air distribution in CNC machinery
- Vacuum system plumbing in packaging lines
- Instrumentation gas sampling connections
- Hydraulic test bench adapters
Installation protocol:
Apply 1.5-2 wraps of PTFE tape on external threads. Hand-tighten until
O-ring contacts mating surface, then torque to 8-10 N·m using backup wrench.
Avoid overtightening beyond 120° rotation after seal contact.
| Property | Property Value |
|---|---|
| sku | X-ABD0103 |
