Airtac X-ABD Male-Female Straight Thread Connector X-ABD0204
AirTAC X-ABD0204 Fitting - Male/Female Threaded Straight Connector
- Model: X-ABD0204
- Type: Male/Female threaded straight through connector
- Thread Standards: M5×0.8 (Male) / PT1/8 (Female)
- Material: Brass with nickel plating
- Seal Material: NBR (Nitrile rubber)
- Operating Pressure: 0.05–1.0 MPa
- Proof Pressure: 1.5 MPa
- Burst Pressure: ≥3.0 MPa
- Temperature Range: -20℃ to 80℃
- Weight: 8g ±0.5g
- Dimensions: 22mm(L) × 12mm(W) × 12mm(H)
- Surface Roughness: Ra ≤1.6μm (sealing surfaces)
- Installation Torque: 0.5–0.7 N·m
- Leakage Rate: <0.1 mL/min at 0.5 MPa
- Vibration Resistance: 10–2000Hz, 1.5mm amplitude
- Protection Rating: IP40 (dust protected)
A precision-machined transition fitting designed for hybrid pneumatic systems requiring mixed thread standards. Features corrosion-resistant nickel plating and dual O-ring retention grooves for leak-free transitions between metric male (M5) and BSPT female (PT1/8) connections. The compact hexagonal body allows tool tightening in confined spaces.
- Adapter for international equipment integration (EU/Asia pneumatic systems)
- Sensor mounting brackets in automated assembly lines
- Medical device pneumatic interfaces
- Packaging machine air circuit transitions
- Laboratory instrumentation gas line conversions
Installation note:
Apply 1.5–2 wraps of PTFE tape on male threads at 30° offset angle.
Use calibrated torque wrench to prevent brass deformation.
Avoid contact with ammonia-based lubricants to prevent stress corrosion.
- Inspect O-rings every 6 months or 5,000 actuations
- Lubricate with PAG-based grease (ISO VG32 equivalent)
- Max re-tightening cycles: 3 times before seal replacement
| Property | Property Value |
|---|---|
| sku | X-ABD0204 |
