Airtac X-ABF Union - Female Thread with Lock Nut, Straight Terminal X-ABF1004
AirTAC X-ABF1004 Internal Thread Straight Terminal with Locknut Specifications
- Model: X-ABF1004
- Type: Straight terminal with female thread and locknut
- Thread specification: M10×1.0 internal thread (ISO 6149 standard)
- Material: Stainless steel (SUS303) body + brass locknut
- Surface treatment: Electropolished (Ra ≤0.8μm)
- Pressure rating: 0.05–1.5 MPa
- Temperature range: -20℃ to 150℃
- Seal material: FKM (Fluoroelastomer) O-ring
- Torque resistance: ≤35 N·m
- Vibration resistance: 10–2000 Hz, 15G acceleration
- Weight: 48±2g
- Dimensions: 28mm(Ø) × 35mm(L)
- Compliance: RoHS 2.0 compliant
High-precision pneumatic terminal connector featuring dual-seal structure with primary metal-to-metal sealing and secondary elastomer backup. The hexagonal locknut design enables 360° adjustable positioning while maintaining torque stability. Electropolished surface minimizes particulate generation in cleanroom environments.
- High-vacuum pneumatic systems (semiconductor manufacturing)
- Robotic end effector tooling connections
- Medical gas line distribution panels
- High-cycle automation fixtures (>500,000 cycles)
- Corrosive environment chemical processing equipment
Installation protocol:
Apply 0.5–1.5 N·m tightening torque using calibrated torque wrench.
Use thread sealant (PTFE-free recommended) only on male threads.
Avoid overtightening – maximum 2 full turns after hand-tight.
| Property | Property Value |
|---|---|
| sku | X-ABF1004 |
