Airtac X-ABF Union - Female Thread with Lock Nut, Straight Terminal X-ABF1004A
AirTAC X-ABF1004A Connector-Locknut Internal Thread Straight Terminal
- Model: X-ABF1004A
- Type: Male-to-Female Straight Threaded Terminal
- Thread Standard: Metric/PT Hybrid
- Male Thread: M5×0.8 (External)
- Female Thread: PT1/8 (BSPP)
- Material: Brass (Nickel-plated surface)
- Seal Material: NBR O-ring
- Max Pressure: 1.0 MPa
- Operating Pressure Range: 0.05-1.0 MPa
- Temperature Range: -20℃ to 80℃
- Weight: 12g ±0.5g
- Dimensions: 38mm(Total Length) × 12mm(Max Diameter)
- Hex Size: 8mm Wrench Flat
- Surface Roughness: Ra ≤3.2μm
- Compliance: ISO 1179-1 Standard
Precision-machined hybrid thread adapter featuring dual sealing (metal-to-metal + elastic seal) for leak-free connections in pneumatic systems. The chrome-plated brass construction resists corrosion from compressed air moisture. Anti-vibration locknut design maintains torque retention under pulsation.
- Transition between metric and BSPP threads in compact spaces
- Terminal connections for pneumatic manifolds
- Sensor/valve mounting in robotic end effectors
- Medical gas line interfaces
- Food machinery requiring frequent disassembly
Installation note:
Apply 2-3 wraps of PTFE tape on male threads (avoiding first thread).
Tighten to 1.2-1.5 N·m torque. For vibration-prone environments,
apply thread locker on locknut.
| Property | Property Value |
|---|---|
| sku | X-ABF1004A |
