Airtac X-ABF Union - Female Thread with Lock Nut, Straight Terminal X-ABF401A
AirTAC X-ABF401A Straight Threaded Terminal with Locknut Specifications
- Model: X-ABF401A
- Type: Female-threaded straight terminal with integrated locknut
- Thread standard: Metric (M5×0.8 internal thread)
- Material: Nickel-plated brass (EN 12165 CW617N)
- Pressure rating: 0.05–1.0 MPa
- Temperature range: -20℃ to 150℃ (instantaneous peak 180℃)
- Seal type: Precision-molded NBR O-ring (AS568A-008 standard)
- Locknut torque: Recommended 0.7–1.2 N·m
- Weight: 8.5±0.3g
- Dimensions: 16.5mm(L) × 10mm(Hex width) × 8mm(Thread OD)
- Surface roughness: Ra ≤3.2μm (sealing surfaces)
- Certification: RoHS compliant, REACH SVHC-free
High-density brass terminal connector featuring dual-stage sealing with precision-machined threads and anti-vibration locknut. The 60° conical seat design ensures leak-free connections in high-cycle applications. Compatible with PU/Nylon tubing (4mm OD). Includes integrated dust shield groove for optional protective caps.
- Modular pneumatic manifolds requiring compact terminals
- Robotic end effector air supply connections
- Medical device gas line terminations
- Semiconductor wafer handling equipment
- High-cycle test bench pneumatic circuits
Installation protocol:
Hand-tighten until seated, then apply 1/8 turn with wrench.
Always use backup wrench on hex body during final tightening.
Replace O-ring after 5 installation cycles.
| Property | Property Value |
|---|---|
| sku | X-ABF401A |
