Airtac X-ABF Union - Female Thread with Lock Nut, Straight Terminal X-ABF601
AirTAC X-ABF601 Fitting-Locknut Internal Thread Straight Terminal Specifications
- Model: X-ABF601
- Thread Type: Internal thread (Female) with locknut
- Port Size: G1/8 (ISO228 standard)
- Alternative Threads: NPT1/8 available on request
- Material: Brass with nickel-plated surface
- Seal Material: NBR (Nitrile) O-ring
- Pressure Range: 0.05–1.0 MPa (7–145 psi)
- Temperature Range: -20℃ to 80℃ (-4°F to 176°F)
- Proof Pressure: 1.5 MPa
- Burst Pressure: ≥3.0 MPa
- Weight: 18.5g ±0.5g
- Dimensions: 30mm(L) × 10mm(OD) × 10mm(Thread Diameter)
- Surface Roughness: Ra ≤3.2μm
- Tightening Torque: 1.2–1.5 N·m
- Vibration Resistance: 10–55Hz, 1.5mm amplitude
Straight-through terminal fitting designed for secure branch connections in pneumatic systems. Features double-secured locking with integrated hex nut and compression ring, preventing vibration-induced loosening. The electroless nickel plating provides corrosion resistance in humid environments.
- Terminal connections for pneumatic cylinders in assembly lines
- Modular manifold systems requiring quick branch extensions
- Food packaging machinery (NBR compatible with food-grade air)
- Robotic arm pneumatic circuit distribution
- Compressed air leak test equipment
Installation protocol:
Hand-tighten until snug, then apply 1/4 turn with wrench. Always use
thread sealant tape (PTFE) on male threads. Maximum angular deviation
after installation ≤3° from axis.
| Property | Property Value |
|---|---|
| sku | X-ABF601 |
