Airtac X-ABF Union - Female Thread with Lock Nut, Straight Terminal X-ABF602
AirTAC X-ABF602 Female Threaded Straight Connector with Locknut Specifications
- Model: X-ABF602
- Type: Straight terminal connector (internal thread)
- Port Thread: M5×0.8 female thread (dual-thread structure)
- Locknut Thread: M12×1.0 hex nut
- Material: Nickel-plated brass body
- Seal Material: NBR (Nitrile) O-rings
- Max Working Pressure: 1.5 MPa (217 PSI)
- Temperature Range: -20℃ to 80℃ (-4°F to 176°F)
- Proof Pressure: 2.25 MPa
- Burst Pressure: ≥3 MPa
- Surface Treatment: Electroless nickel plating (8-12μm)
- Weight: 8.2 grams
- Dimensions: 16mm (L) × 12mm (W) × 12mm (H)
- Compliance: RoHS 2.0 compliant
- Vibration Resistance: 10-55Hz, 1.5mm amplitude
A precision-machined pneumatic connector featuring dual-thread locking mechanism for secure tubing connections. The hexagonal locknut design enables tool-assisted tightening with 8-10N·m recommended torque. Nickel plating provides corrosion resistance in humid environments. Compatible with 4mm OD polyurethane/nylon tubing.
- Pneumatic valve terminal connections
- Compact sensor air supply interfaces
- Robotic end-effector pneumatic lines
- Medical device gas delivery systems
- Automated packaging machine air circuits
Installation protocol:
Apply thread sealant (LOCTITE 5452 recommended) on male threads before assembly.
Use backup wrench on hex body during locknut tightening to prevent rotation.
Maximum 3 reuses recommended for optimal sealing performance.
| Property | Property Value |
|---|---|
| sku | X-ABF602 |
