Airtac X-ABF Union - Female Thread with Lock Nut, Straight Terminal X-ABF801
AirTAC X-ABF801 Female Threaded Straight Terminal with Locknut Specifications
- Model: X-ABF801
- Type: Straight terminal with female threads and hex locknut
- Thread standard: Metric (M5×0.8)
- Material: Nickel-plated brass body, PPS resin locknut
- Seal type: Integrated O-ring (NBR material)
- Pressure rating: 0.05–1.0 MPa
- Temperature range: -20℃ to 80℃ (continuous use)
- Thread engagement: 8±0.5mm
- Hex size: 18mm wrench flat
- Surface roughness: Ra ≤3.2μm (sealing surfaces)
- Vibration resistance: 10–55Hz, 1.5mm amplitude
- Weight: 32g ±2g
- Dimensions: 35mm(L) × 18mm(Ø) × 18mm(Hex width)
Precision-machined terminal connector featuring anti-vibration locknut design with 120° rotation range. The dual-seal structure combines metal-to-metal sealing with elastic O-ring compression, ensuring leak-free connections in dynamic systems. Nickel plating provides corrosion resistance against hydraulic oils and mild chemicals.
- Pneumatic cylinder port connections
- Modular valve manifold assemblies
- Sensor mounting interfaces in automated machinery
- Air brake system junctions in commercial vehicles
- Laboratory equipment gas line terminations
Installation protocol:
Hand-tighten locknut until resistance is felt, then apply 1/4 turn with wrench.
Always use backup wrench on terminal body during final tightening.
Maximum recommended torque: 12N·m.
| Property | Property Value |
|---|---|
| sku | X-ABF801 |
